增加zxing识别二维码和锐化处理

pom.xml

@@ -211,11 +211,23 @@
             <artifactId>tess4j</artifactId>
             <version>3.0.0</version>
         </dependency>  -->
- <dependency>
-    <groupId>net.sourceforge.tess4j</groupId>
-    <artifactId>tess4j</artifactId>
-    <version>3.0.0</version>
-</dependency>
+	 <dependency>
+	    <groupId>net.sourceforge.tess4j</groupId>
+	    <artifactId>tess4j</artifactId>
+	    <version>3.0.0</version>
+	</dependency>
+	<!--zxing二维码识别 -->
+	<dependency>
+	    <groupId>com.google.zxing</groupId>
+	    <artifactId>core</artifactId>
+	    <version>3.3.0</version>
+	</dependency>
+	<!-- com.google.zxing/javase -->
+	<dependency>
+	    <groupId>com.google.zxing</groupId>
+	    <artifactId>javase</artifactId>
+	    <version>3.3.0</version>
+	</dependency>


   </dependencies>

src/main/java/com/acts/opencv/base/BaseMethodController.java

@@ -1,7 +1,11 @@
 package com.acts.opencv.base;

+import java.awt.image.BufferedImage;
 import java.io.IOException;
 import java.util.ArrayList;
+import java.util.HashMap;
+import java.util.List;
+import java.util.Map;
 import java.util.Vector;

 import javax.servlet.http.HttpServletResponse;
@@ -29,6 +33,14 @@ import com.acts.opencv.common.utils.Constants;
 import com.acts.opencv.common.utils.OpenCVUtil;
 import com.acts.opencv.common.web.BaseController;
 import com.acts.opencv.demo.DemoController;
+import com.google.zxing.Binarizer;
+import com.google.zxing.BinaryBitmap;
+import com.google.zxing.DecodeHintType;
+import com.google.zxing.LuminanceSource;
+import com.google.zxing.MultiFormatReader;
+import com.google.zxing.Result;
+import com.google.zxing.client.j2se.BufferedImageLuminanceSource;
+import com.google.zxing.common.HybridBinarizer;


 @Controller
@@ -178,6 +190,99 @@ public class BaseMethodController extends BaseController {

 	}

+	/**
+	 * 自适用二值化+zxing识别条形码
+	 * @Author 王嵩
+	 * @param response
+	 * @param imagefile
+	 * @param binaryType 二值化类型
+	 * @param blockSize 附近区域面积
+	 * @param constantC 它只是一个常数，从平均值或加权平均值中减去的常数
+	 * @Date 2018年5月17日
+	 * 更新日志
+	 * 2018年5月17日 王嵩  首次创建
+	 */
+	@RequestMapping(value = "zxing")
+	public void zxing(HttpServletResponse response, String imagefile, Integer adaptiveMethod, Integer binaryType,
+			Integer blockSize, Double constantC) {
+		//
+		System.loadLibrary(Core.NATIVE_LIBRARY_NAME);
+		logger.info("\n 自适用二值化方法");
+
+		// 灰度化
+		// Imgproc.cvtColor(source, destination, Highgui.CV_LOAD_IMAGE_GRAYSCALE);
+		String sourcePath = Constants.PATH + imagefile;
+		logger.info("url==============" + sourcePath);
+		// 加载为灰度图显示
+		Mat source = Highgui.imread(sourcePath, Highgui.CV_LOAD_IMAGE_GRAYSCALE);
+		Mat destination = new Mat(source.rows(), source.cols(), source.type());
+		logger.info("binaryType:{},blockSize:{},constantC:{}", binaryType, blockSize, constantC);
+		switch (adaptiveMethod) {
+		case 0:
+			adaptiveMethod = Imgproc.ADAPTIVE_THRESH_MEAN_C;
+			break;
+		case 1:
+			adaptiveMethod = Imgproc.ADAPTIVE_THRESH_GAUSSIAN_C;
+			break;
+		}
+
+		switch (binaryType) {
+		case 0:
+			binaryType = Imgproc.THRESH_BINARY;
+			break;
+		case 1:
+			binaryType = Imgproc.THRESH_BINARY_INV;
+			break;
+		case 2:
+			binaryType = Imgproc.THRESH_TRUNC;
+			break;
+		case 3:
+			binaryType = Imgproc.THRESH_TOZERO;
+			break;
+		case 4:
+			binaryType = Imgproc.THRESH_TOZERO_INV;
+			break;
+		default:
+			break;
+		}
+		// Imgproc.adaptiveThreshold(source, destination, 255, adaptiveMethod, binaryType, blockSize, constantC);
+		Imgproc.threshold(source, destination, 190, 255, Imgproc.THRESH_BINARY);
+		String result = parseCode(destination);
+
+		renderString(response, result);
+
+	}
+
+	private static String parseCode(Mat mat) {
+		String resultText = "无法识别！！！";
+		try {
+			MultiFormatReader formatReader = new MultiFormatReader();
+			// if (!file.exists()) {
+			// System.out.println("nofile");
+			// return;
+			// }
+			// BufferedImage image = ImageIO.read(file);
+
+			BufferedImage image = OpenCVUtil.toBufferedImage(mat);
+			LuminanceSource source = new BufferedImageLuminanceSource(image);
+			Binarizer binarizer = new HybridBinarizer(source);
+			BinaryBitmap binaryBitmap = new BinaryBitmap(binarizer);
+
+			Map<DecodeHintType, String> hints = new HashMap<DecodeHintType, String>();
+			hints.put(DecodeHintType.CHARACTER_SET, "UTF-8");
+
+			Result result = formatReader.decode(binaryBitmap, hints);
+			StringBuffer sbuffer = new StringBuffer();
+			sbuffer.append("解析结果 = " + result.toString() + "\n");
+			sbuffer.append("二维码格式类型 = " + result.getBarcodeFormat() + "\n");
+			sbuffer.append("二维码文本内容 = " + result.getText() + "\n");
+			resultText = sbuffer.toString();
+		} catch (Exception e) {
+			e.printStackTrace();
+		}
+		return resultText;
+	}
+
 	/**
 	 * 高斯滤波方法测试
 	 * 创建者 Songer
@@ -205,6 +310,44 @@ public class BaseMethodController extends BaseController {
 		}
 	}

+	/**
+	 * 图像锐化操作
+	 * @Author 王嵩
+	 * @param response
+	 * @param imagefile
+	 * @param ksize 中值滤波内核size
+	 * @param alpha 控制图层src1的透明度
+	 * @param beta 控制图层src2的透明度
+	 * @param gamma gamma越大合并的影像越明亮 void
+	 * @Date 2018年5月18日
+	 * 更新日志
+	 * 2018年5月18日 王嵩  首次创建
+	 *
+	 */
+	@RequestMapping(value = "sharpness")
+	public void sharpness(HttpServletResponse response, String imagefile, int ksize, double alpha, double beta,
+			double gamma) {
+		System.loadLibrary(Core.NATIVE_LIBRARY_NAME);
+		logger.info("\n 锐化操作");
+
+		String sourcePath = Constants.PATH + imagefile;
+		logger.info("url==============" + sourcePath);
+		Mat source = Highgui.imread(sourcePath, Highgui.CV_LOAD_IMAGE_COLOR);
+		Mat destination = new Mat(source.rows(), source.cols(), source.type());
+		// 先进行中值滤波操作
+		Imgproc.medianBlur(source, destination, 2 * ksize + 1);
+		// 通过合并图层的方式进行效果增强 alpha控制src1的透明度，beta控制src2 的透明图；gamma越大合并的影像越明亮
+		// public static void addWeighted(Mat src1, double alpha, Mat src2, double beta, double gamma, Mat dst)
+		Core.addWeighted(source, alpha, destination, beta, 0, destination);
+
+		try {
+			byte[] imgebyte = OpenCVUtil.covertMat2Byte1(destination);
+			renderImage(response, imgebyte);
+		} catch (IOException e) {
+			e.printStackTrace();
+		}
+	}
+
 	/**
 	 * 图片缩放方法测试
 	 * 创建者 Songer
@@ -630,6 +773,7 @@ public class BaseMethodController extends BaseController {
 		Core.normalize(destination, destination, 0, 255, Core.NORM_MINMAX, -1, new Mat());
 		// minMaxLoc(imagematch, minVal, maxVal2, minLoc, maxLoc01, new Mat());
 		MinMaxLocResult minmaxLoc = Core.minMaxLoc(destination);
+		logger.info("相似值=================：最大：" + minmaxLoc.maxVal + "    最小：" + minmaxLoc.minVal);
 		Point matchLoc = new Point();
 		switch (method) {
 		case 0:
@@ -695,7 +839,7 @@ public class BaseMethodController extends BaseController {
 		logger.info("\n 灰度直方图测试");
 		String sourcePath = Constants.PATH + imagefile;
 		Mat source = Highgui.imread(sourcePath, Highgui.CV_LOAD_IMAGE_GRAYSCALE);
-		java.util.List<Mat> images = new ArrayList<>();
+		List<Mat> images = new ArrayList<Mat>();
 		images.add(source);
 		MatOfInt channels = new MatOfInt(0); // 图像通道数，0表示只有一个通道
 		MatOfInt histSize = new MatOfInt(cols); // CV_8U类型的图片范围是0~255，共有256个灰度级

src/main/java/com/acts/opencv/common/utils/OpenCVUtil.java

@@ -1,6 +1,5 @@
 package com.acts.opencv.common.utils;

-import java.awt.Image;
 import java.awt.image.BufferedImage;
 import java.awt.image.DataBufferByte;
 import java.io.IOException;
@@ -19,7 +18,7 @@ public class OpenCVUtil {
 	public static BufferedImage covertMat2Buffer(Mat mat) throws IOException {
 		long time1 = new Date().getTime();
 		// Mat 转byte数组
-		BufferedImage originalB = (BufferedImage) toBufferedImage(mat);
+		BufferedImage originalB = toBufferedImage(mat);
 		long time3 = new Date().getTime();
 		System.out.println("保存读取方法2转=" + (time3 - time1));
 		return originalB;
@@ -48,7 +47,7 @@ public class OpenCVUtil {
 		return mob.toArray();
 	}

-	public static Image toBufferedImage(Mat m) {
+	public static BufferedImage toBufferedImage(Mat m) {
 		int type = BufferedImage.TYPE_BYTE_GRAY;
 		if (m.channels() > 1) {
 			type = BufferedImage.TYPE_3BYTE_BGR;

src/main/resources/database.properties

@@ -1,7 +1,7 @@
 driverClassName = com.mysql.jdbc.Driver
-#url=jdbc:mysql://192.168.1.61:3306/acts_java_opencv?characterEncoding=UTF-8&useSSL=false
-#username = root
-#password = root
+url=jdbc:mysql://192.168.1.61:3306/acts_java_opencv?characterEncoding=UTF-8&useSSL=false
+username = root
+password = root
 initialSize = 10
 maxActive = 15
 minIdle = 3

src/main/webapp/index.jsp

@@ -127,7 +127,9 @@ desired effect
 			          <ul class="treeview-menu">
 			            <li><a href="#view/base/binary.jsp"><i class="fa fa-circle-o"></i>二值化</a></li>
 			            <li><a href="#view/base/adaptiveBinary.jsp"><i class="fa fa-circle-o"></i>自适用二值化</a></li>
+			            <li><a href="#view/base/zxing.jsp"><i class="fa fa-circle-o"></i>zxing识别二维码</a></li>
 			            <li><a href="#view/base/gaussian.jsp"><i class="fa fa-circle-o"></i> 模糊</a></li>
+			            <li><a href="#view/base/sharpness.jsp"><i class="fa fa-circle-o"></i> 图像锐化</a></li>
 			            <li><a href="#view/base/resize.jsp"><i class="fa fa-circle-o"></i> 缩放</a></li>
 			            <li><a href="#view/base/erosion_dilation.jsp"><i class="fa fa-circle-o"></i>腐蚀膨胀</a></li>
 			            <li><a href="#view/base/morphologyEx.jsp"><i class="fa fa-circle-o"></i>腐蚀膨胀进阶</a></li>

src/main/webapp/view/base/sharpness.jsp

@@ -0,0 +1,227 @@
+<%@ page language="java" import="java.util.*" pageEncoding="UTF-8"%>
+<%@include file="/module/include/common.jsp"%>
+<!DOCTYPE html>
+<html>
+<head>
+    <sys:header title="首页" extLibs=""></sys:header>
+	<link rel="stylesheet" href="${ctxStatic}/plugins/bootstrap-slider/slider.css">
+    <script type="text/javascript">
+		$(function(){
+			var baseImageFile = "/statics/sourceimage/ticket1.png"
+			var newImagePath = "/statics/distimage/lena.png"
+			$("#oldimg").attr("src",baseUrl+baseImageFile);
+			//$("#newimg").attr("src",baseUrl+baseImageFile);
+
+			//锐化
+			$("#sharpness").click(function(){
+				var ksize = $("#ksize").val();
+				var alpha = $("#alpha").val();
+				var beta = $("#beta").val();
+				var gamma = $("#gamma").val();
+				//alert(ksize+"|"+alpha+"|"+beta+"|"+gamma);
+				var imagefile = baseImageFile;
+				var srcurl = ctxPath+"/base/sharpness?_" + $.now()+"&ksize="+ksize+"&alpha="+alpha+"&beta="+beta+"&gamma="+gamma+"&imagefile="+baseImageFile;
+				$("#newimg").attr("src",srcurl);
+			});
+
+			//重置
+			$("#reset").click(function(){
+				var baseImageFile = "/statics/sourceimage/lena.png";
+				$("#oldimg").attr("src",baseUrl+baseImageFile);
+				$("#newimg").attr("src",'');
+				layer.msg('重置成功!', {icon: 1});
+			});
+
+			//滑动插件加载
+			$("#ksize").slider({
+				tooltip: 'always',
+			});
+			$("#alpha").slider({
+				tooltip: 'always',
+			});
+			$("#beta").slider({
+				tooltip: 'always',
+			});
+			$("#gamma").slider({
+				tooltip: 'always',
+			});
+
+ 			$("#ksize").on("slide", function(slideEvt) {
+				console.log(slideEvt.value);
+				//$("#binary").click();
+			}).on("change", function (e) {
+			    //当值发生改变的时候触发
+			    //console.info(e);
+			    //获取旧值和新值
+			    console.info(e.value.oldValue + '--' + e.value.newValue);
+				$("#ksize").val(e.value.newValue);
+			    $("#sharpness").click();
+			});
+
+ 			$("#alpha").on("slide", function(slideEvt) {
+				console.log(slideEvt.value);
+				//$("#binary").click();
+			}).on("change", function (e) {
+			    //当值发生改变的时候触发
+			    //console.info(e);
+			    //获取旧值和新值
+			    console.info(e.value.oldValue + '--' + e.value.newValue);
+				$("#alpha").val(e.value.newValue);
+			    $("#sharpness").click();
+			});
+
+ 			$("#beta").on("slide", function(slideEvt) {
+				console.log(slideEvt.value);
+				//$("#binary").click();
+			}).on("change", function (e) {
+			    //当值发生改变的时候触发
+			    //console.info(e);
+			    //获取旧值和新值
+			    console.info(e.value.oldValue + '--' + e.value.newValue);
+				$("#beta").val(e.value.newValue);
+			    $("#sharpness").click();
+			});
+
+ 			$("#gamma").on("slide", function(slideEvt) {
+				console.log(slideEvt.value);
+				//$("#binary").click();
+			}).on("change", function (e) {
+			    //当值发生改变的时候触发
+			    //console.info(e);
+			    //获取旧值和新值
+			    console.info(e.value.oldValue + '--' + e.value.newValue);
+				$("#gamma").val(e.value.newValue);
+			    $("#sharpness").click();
+			});
+		});
+
+
+
+	</script>
+</head>
+<body>
+
+              <div class="box-group" id="accordion">
+                <!-- we are adding the .panel class so bootstrap.js collapse plugin detects it -->
+                <div class="panel box box-primary">
+                  <div class="box-header with-border">
+                    <h4 class="box-title">
+                      <a data-toggle="collapse" data-parent="#accordion" href="#collapseOne">
+                       addweighted
+                      </a>
+                    </h4>
+                  </div>
+                  <div id="collapseOne" class="panel-collapse collapse"><!--class="panel-collapse collapse in"中的 in 控制展开 -->
+                    <div class="box-body">
+                      		<h4>参考资料：<br>
+                      		<a href="https://docs.opencv.org/2.4.13.6/modules/core/doc/operations_on_arrays.html#addweighted">Opencv官方文档：addweighted</a> <br>
+                      		<br>锐化：dst (I)= saturate ( src1(I)* alpha +  src2(I)* beta +  gamma )
+                      		 public static void addWeighted(Mat src1, double alpha, Mat src2, double beta, double gamma, Mat dst); 各参数说明：</h4>
+                      		<table class="table table-bordered">
+				                <tbody><tr>
+				                  <th style="width: 10px">#</th>
+				                  <th style="width: 20%">参数</th>
+				                  <th>说明</th>
+				                </tr>
+				                <tr>
+				                  <td>1.</td>
+				                  <td>Mat src1</td>
+				                  <td>图层1对应的Mat对象</td>
+				                </tr>
+				                <tr>
+				                  <td>2.</td>
+				                  <td>double alpha</td>
+				                  <td>图层1的透明度权重</td>
+				                </tr>
+				                <tr>
+				                  <td>3.</td>
+				                  <td>Mat src2</td>
+				                  <td>图层2对应的Mat对象</td>
+				                </tr>
+				                <tr>
+				                  <td>4.</td>
+				                  <td>double beta</td>
+				                  <td>图层2的透明度权重</td>
+				                </tr>
+				                <tr>
+				                  <td>5.</td>
+				                  <td>double gamma</td>
+				                  <td>一个加到权重总和上的标量值，越大合并图像越明亮</td>
+				                </tr>
+				                <tr>
+				                  <td>6.</td>
+				                  <td>Mat dst</td>
+				                  <td>目标图像mat</td>
+				                </tr>
+				              </tbody></table>
+
+
+                      </div>
+                  </div>
+                </div>
+            </div>
+            <!-- /.box-body -->
+
+            <h4>&nbsp;&nbsp;高斯滤波测试</h4>
+    			 <div class="box-body">
+    			<table class="table table-bordered">
+                <tbody><tr>
+                  <th style="width:20%">中值滤波ksize 内核大小=2*ksize+1</th>
+                  <th style="width:20%">alpha图层1的透明度</th>
+                  <th style="width:20%">beta图层2的透明度</th>
+                  <th style="width:20%">gamma合并图像亮度</th>
+                  <th style="width: 200px">操作</th>
+                </tr>
+                <tr>
+                  <td>
+                  		<input id="ksize" data-slider-id='ex1Slider' type="text" data-slider-min="0" data-slider-max="10" data-slider-step="1" data-slider-value="3"/>
+				  </td>
+                  <td>
+                  		<input id="alpha" data-slider-id='ex1Slider' type="text" data-slider-min="0" data-slider-max="4" data-slider-step="0.1" data-slider-value="2.1"/>
+                  </td>
+                  <td>
+                  		<input id="beta" data-slider-id='ex1Slider' type="text" data-slider-min="-2" data-slider-max="2" data-slider-step="0.1" data-slider-value="-1.1"/>
+                  </td>
+                  <td>
+                  		<input id="gamma" data-slider-id='ex1Slider' type="text" data-slider-min="0" data-slider-max="100" data-slider-step="1" data-slider-value="0"/>
+                  </td>
+                  <td><a class="btn btn-info"  id="sharpness"><i class="fa fa-object-ungroup"></i>锐化</a>
+			          <a class="btn btn-info" id="reset"><i class="fa fa-refresh"></i>重置</a></td>
+                </tr>
+              </tbody></table></div>
+
+
+
+
+			<div class="row">
+			    <div class="col-sm-6">
+			      <div class="box box-primary">
+			        <div class="box-header with-border">
+			          <h3 class="box-title">原图</h3>
+			          <span class="label label-primary pull-right"><i class="fa fa-html5"></i></span>
+			        </div><!-- /.box-header -->
+			        <div class="box-body">
+			          <p>未识别前的原文件。</p>
+		          		<img id="oldimg" src=""  alt="原图" />
+			        </div><!-- /.box-body -->
+			      </div><!-- /.box -->
+			    </div><!-- /.col -->
+			    <div class="col-sm-6">
+			      <div class="box box-danger">
+			        <div class="box-header with-border">
+			          <h3 class="box-title">识别后的图片</h3>
+			          <span class="label label-danger pull-right"><i class="fa fa-database"></i></span>
+			        </div><!-- /.box-header -->
+			        <div class="box-body">
+			          <p>点击识别按钮后，将显示识别后的文件。</p>
+			          <img  id="newimg" src=""  alt="识别后的图" />
+
+			        </div><!-- /.box-body -->
+			      </div><!-- /.box -->
+			    </div><!-- /.col -->
+			  </div>
+
+
+</body>
+<script src="${ctxStatic}/plugins/bootstrap-slider/bootstrap-slider.js?t=${version}"></script>
+</html>

src/main/webapp/view/base/zxing.jsp

@@ -0,0 +1,265 @@
+<%@ page language="java" import="java.util.*" pageEncoding="UTF-8"%>
+<%@include file="/module/include/common.jsp"%>
+<!DOCTYPE html>
+<html>
+<head>
+    <sys:header title="首页" extLibs=""></sys:header>
+	<link rel="stylesheet" href="${ctxStatic}/plugins/iCheck/all.css?t=${version}">
+	<link rel="stylesheet" href="${ctxStatic}/plugins/bootstrap-slider/slider.css">
+	<link rel="stylesheet" href="${ctxStatic}/plugins/iCheck/minimal/blue.css?t=${version}">
+    <script type="text/javascript">
+		$(function(){
+			var baseImageFile = "/statics/sourceimage/ticket.png"
+			var newImagePath = "/statics/distimage/lena.png"
+			$("#oldimg").attr("src",baseUrl+baseImageFile);
+			//$("#newimg").attr("src",baseUrl+baseImageFile);
+
+
+			$("#binary").click(function(){
+				var binaryType = $("input[name='thresh_type']:checked").val();
+				var adaptiveMethod = $("input[name='adaptiveMethod']:checked").val();
+				var blockSize = $("#block_value").val();
+				var constantC = $("#constantC").val();
+				var imagefile = baseImageFile;
+			 	$.SaveForm({
+					url : ctxPath+"/base/zxing?_" + $.now(),
+					param: {"binaryType":binaryType,"blockSize":blockSize,"adaptiveMethod":adaptiveMethod,"constantC":constantC,"imagefile":baseImageFile},
+					json:true,
+					success : function(result) {
+						$("#zxingResult").html(result);
+						layer.msg('操作成功!', {icon: 1});
+					}
+				});
+			});
+
+			//重置
+			$("#reset").click(function(){
+				var baseImageFile = "/statics/sourceimage/ticket.jpg";
+				$("#oldimg").attr("src",baseUrl+baseImageFile);
+				$("#newimg").attr("src",'');
+				layer.msg('重置成功!', {icon: 1});
+			});
+
+			//滑动插件加载
+			$("#block_value,#constantC").slider({
+				tooltip: 'always',
+			});
+
+ 			$("#constantC").on("slide", function(slideEvt) {
+				console.log(slideEvt.value);
+				//$("#binary").click();
+			}).on("change", function (e) {
+			    //当值发生改变的时候触发
+			    //console.info(e);
+			    //获取旧值和新值
+			    console.info(e.value.oldValue + '--' + e.value.newValue);
+			    $("#constantC").val(e.value.newValue)
+			    $("#binary").click();
+			});
+
+ 			$("#block_value").on("slide", function(slideEvt) {
+				console.log(slideEvt.value);
+				//$("#binary").click();
+			}).on("change", function (e) {
+			    //当值发生改变的时候触发
+			    //console.info(e);
+			    //获取旧值和新值
+			    console.info(e.value.oldValue + '--' + e.value.newValue);
+			    $("#block_value").val(e.value.newValue)
+			    $("#binary").click();
+			});
+			//iCheck样式加载
+		  	$("input[name='thresh_type'],input[name='adaptiveMethod']").iCheck({
+			    checkboxClass: 'icheckbox_flat',
+			    radioClass: 'iradio_flat'
+			 });
+
+			//type类型更换时自动生成
+		  	$("input[name='thresh_type'],input[name='adaptiveMethod']").on('ifChecked', function(event){
+		  		$("#binary").click();
+		  	 	 //alert($(event).text());
+		  	});
+		});
+
+
+	</script>
+</head>
+<body>
+
+                <div class="box-body">
+              <div class="box-group" id="accordion">
+                <!-- we are adding the .panel class so bootstrap.js collapse plugin detects it -->
+                <div class="panel box box-primary">
+                  <div class="box-header with-border">
+                    <h4 class="box-title">
+                      <a data-toggle="collapse" data-parent="#accordion" href="#collapseOne">
+                        1.adaptivethreshold函数介绍
+                      </a>
+                    </h4>
+                  </div>
+                  <div id="collapseOne" class="panel-collapse collapse"><!--class="panel-collapse collapse in"中的 in 控制展开 -->
+                    <div class="box-body">
+                      		<h4>参考资料：<br>
+                      		<a href="https://docs.opencv.org/2.4.13.6/modules/imgproc/doc/miscellaneous_transformations.html#adaptivethreshold">https://docs.opencv.org/2.4.13.6/modules/imgproc/doc/miscellaneous_transformations.html#adaptivethreshold</a> <br>
+                      		<br>
+                      		public static void adaptiveThreshold(Mat src, Mat dst, double maxValue, int adaptiveMethod, int thresholdType, int blockSize, double C); 各参数说明：
+                      		adaptiveThreshold()支持两种自适应方法，即ADAPTIVE_THRESH_MEAN_C（平均）和ADAPTIVE_THRESH_GAUSSIAN_C（高斯）。
+                      		在两种情况下，自适应阈值T(x, y)。通过计算每个像素周围bxb大小像素块的加权均值并减去常量C得到。其中，
+                      		b由blockSize给出，大小必须为奇数；如果使用平均的方法，则所有像素周围的权值相同；
+                      		如果使用高斯的方法，则（x,y）周围的像素的权值则根据其到中心点的距离通过高斯方程得到。
+                      		</h4>
+                      		<table class="table table-bordered">
+				                <tbody><tr>
+				                  <th style="width: 10px">#</th>
+				                  <th style="width: 20%">参数</th>
+				                  <th>说明</th>
+				                </tr>
+				                <tr>
+				                  <td>1.</td>
+				                  <td>Mat src</td>
+				                  <td>源文件Mat对象，单通道, 8-bit or 32-bit</td>
+				                </tr>
+				                <tr>
+				                  <td>2.</td>
+				                  <td>Mat dst</td>
+				                  <td>目标文件Mat对象，将和源图片有着相同的大小和类型</td>
+				                </tr>
+				                <tr>
+				                  <td>3.</td>
+				                  <td>double maxValue</td>
+				                  <td>最大像素值</td>
+				                </tr>
+				                <tr>
+				                  <td>4.</td>
+				                  <td>int adaptiveMethod</td>
+				                  <td>自适应方法，平均或高斯</td>
+				                </tr>
+				                <tr>
+				                  <td>5.</td>
+				                  <td>int thresholdType</td>
+				                  <td>二值化类型</td>
+				                </tr>
+				                <tr>
+				                  <td>6.</td>
+				                  <td>int blockSize</td>
+				                  <td>范围对比块大小</td>
+				                </tr>
+				                <tr>
+				                  <td>7.</td>
+				                  <td>double C</td>
+				                  <td>常量</td>
+				                </tr>
+				              </tbody></table>
+
+
+                      </div>
+                  </div>
+                </div>
+                <div class="panel box box-success">
+                  <div class="box-header with-border">
+                    <h4 class="box-title">
+                      <a data-toggle="collapse" data-parent="#accordion" href="#collapseTwo">
+                        2.二值化类型说明
+                      </a>
+                    </h4>
+                  </div>
+                  <div id="collapseTwo" class="panel-collapse collapse">
+                    <div class="box-body">
+							 <table class="table table-bordered">
+				                <tbody><tr>
+				                  <th style="width: 10px">#</th>
+				                  <th style="width: 10%">二值化类型</th>
+				                  <th>公式</th>
+				                  <th>效果图</th>
+				                  <th>解释说明</th>
+				                </tr>
+				                <tr>
+				                  <td>1.</td>
+				                  <td>THRESH_BINARY</td>
+				                  <td><img alt="" src ="${ctxStatic}/images/THRESH_BINARY_1.png"></td>
+				                  <td><img alt="" src="${ctxStatic}/images/THRESH_BINARY_2.png"></td>
+				                  <td>在运用该阈值类型的时候，先要选定一个特定的阈值量，比如：125，这样，新的阈值产生规则可以解释为大于125的像素点的灰度值设定为最大值(如8位灰度值最大为255)，灰度值小于125的像素点的灰度值设定为0。</td>
+				                </tr>
+				                <tr>
+				                  <td>2.</td>
+				                  <td>THRESH_BINARY_INV</td>
+				                  <td><img alt="" src ="${ctxStatic}/images/THRESH_BINARY_INV_1.png"></td>
+				                  <td><img alt="" src="${ctxStatic}/images/THRESH_BINARY_INV_2.png"></td>
+				                  <td>该阈值化与二进制阈值化相似，先选定一个特定的灰度值作为阈值，不过最后的设定值相反。（在8位灰度图中，例如大于阈值的设定为0，而小于该阈值的设定为255）。</td>
+				                </tr>
+				              </tbody>
+				             </table>
+                    </div>
+                  </div>
+                </div>
+              </div>
+            </div>
+            <!-- /.box-body -->
+
+            <h4>
+    			&nbsp;&nbsp;二值化效果测试      </h4>
+    			 <div class="box-body">
+    			<table class="table table-bordered">
+                <tbody><tr>
+                  <th style="width:15%">blockSize</th>
+                  <th style="width:15%">constantC</th>
+                  <th style="width:30%">type</th>
+                  <th style="width:20%">adaptiveMethod</th>
+                  <th style="width: 200px">操作</th>
+                </tr>
+                <tr>
+                  <td>
+                  		<input id="block_value" data-slider-id='ex1Slider' type="text" data-slider-min="1" data-slider-max="51" data-slider-step="2" data-slider-value="31"/>
+				  </td>
+                  <td>
+						<input id="constantC" data-slider-id='ex1Slider' type="text" data-slider-min="1" data-slider-max="50" data-slider-step="1" data-slider-value="15"/>
+				  </td>
+                  <td>
+                  		<input type="radio" name="thresh_type" value="0" checked="checked"/>THRESH_BINARY &nbsp;
+                  		<input type="radio" name="thresh_type" value="1"/>THRESH_BINARY_INV&nbsp;
+                  </td>
+                  <td>
+                  		<input type="radio" name="adaptiveMethod" value="0" checked="checked"/>ADAPTIVE_THRESH_MEAN_C &nbsp;<br>
+                  		<input type="radio" name="adaptiveMethod" value="1"/>ADAPTIVE_THRESH_GAUSSIAN_C&nbsp;
+                  </td>
+                  <td><a class="btn btn-info"  id="binary"><i class="fa fa-object-ungroup"></i>识别</a>
+			          <a class="btn btn-info" id="reset"><i class="fa fa-refresh"></i>重置</a></td>
+                </tr>
+              </tbody></table></div>
+
+
+
+
+			<div class="row">
+			    <div class="col-sm-6">
+			      <div class="box box-primary">
+			        <div class="box-header with-border">
+			          <h3 class="box-title">原图</h3>
+			          <span class="label label-primary pull-right"><i class="fa fa-html5"></i></span>
+			        </div><!-- /.box-header -->
+			        <div class="box-body">
+			          <p>未识别前的原文件。</p>
+		          		<img id="oldimg" src=""  alt="原图" />
+			        </div><!-- /.box-body -->
+			      </div><!-- /.box -->
+			    </div><!-- /.col -->
+			    <div class="col-sm-6">
+			      <div class="box box-danger">
+			        <div class="box-header with-border">
+			          <h3 class="box-title">识别后的图片</h3>
+			          <span class="label label-danger pull-right"><i class="fa fa-database"></i></span>
+			        </div><!-- /.box-header -->
+			        <div class="box-body">
+			          <p>点击识别按钮后，将显示识别后的文件。</p>
+			        	 <div id="zxingResult"></div>
+
+			        </div><!-- /.box-body -->
+			      </div><!-- /.box -->
+			    </div><!-- /.col -->
+			  </div>
+
+
+</body>
+<script src="${ctxStatic}/plugins/bootstrap-slider/bootstrap-slider.js?t=${version}"></script>
+<script src="${ctxStatic}/plugins/iCheck/icheck.js?t=${version}"></script>
+</html>
