!4772 Adding AlbumDataset for device training

Merge pull request !4772 from EricZ/ms-album

build.sh

@@ -393,7 +393,7 @@ build_mindspore()
       CMAKE_VERBOSE="--verbose"
     fi
     cmake --build . --target package ${CMAKE_VERBOSE} -j$THREAD_NUM
-    echo "success to build mindspore project!"
+    echo "success building mindspore project!"
 }

 checkndk() {

mindspore/ccsrc/minddata/dataset/api/datasets.cc

@@ -21,6 +21,7 @@
 #include "minddata/dataset/include/transforms.h"
 #include "minddata/dataset/engine/dataset_iterator.h"
 // Source dataset headers (in alphabetical order)
+#include "minddata/dataset/engine/datasetops/source/album_op.h"
 #include "minddata/dataset/engine/datasetops/source/celeba_op.h"
 #include "minddata/dataset/engine/datasetops/source/cifar_op.h"
 #include "minddata/dataset/engine/datasetops/source/clue_op.h"
@@ -117,6 +118,15 @@ std::shared_ptr<SchemaObj> Schema(const std::string &schema_file) {
 // FUNCTIONS TO CREATE DATASETS FOR LEAF-NODE DATASETS
 // (In alphabetical order)

+// Function to create a AlbumDataset.
+std::shared_ptr<AlbumDataset> Album(const std::string &dataset_dir, const std::string &data_schema,
+                                    const std::vector<std::string> &column_names, bool decode,
+                                    const std::shared_ptr<SamplerObj> &sampler) {
+  auto ds = std::make_shared<AlbumDataset>(dataset_dir, data_schema, column_names, decode, sampler);
+
+  return ds->ValidateParams() ? ds : nullptr;
+}
+
 // Function to create a CelebADataset.
 std::shared_ptr<CelebADataset> CelebA(const std::string &dataset_dir, const std::string &dataset_type,
                                       const std::shared_ptr<SamplerObj> &sampler, bool decode,
@@ -687,6 +697,49 @@ bool ValidateDatasetShardParams(const std::string &dataset_name, int32_t num_sha
 // DERIVED DATASET CLASSES LEAF-NODE DATASETS
 // (In alphabetical order)

+// Constructor for AlbumDataset
+AlbumDataset::AlbumDataset(const std::string &dataset_dir, const std::string &data_schema,
+                           const std::vector<std::string> &column_names, bool decode,
+                           const std::shared_ptr<SamplerObj> &sampler)
+    : dataset_dir_(dataset_dir),
+      schema_path_(data_schema),
+      column_names_(column_names),
+      decode_(decode),
+      sampler_(sampler) {}
+
+bool AlbumDataset::ValidateParams() {
+  if (!ValidateDatasetDirParam("AlbumDataset", dataset_dir_)) {
+    return false;
+  }
+
+  if (!ValidateDatasetFilesParam("AlbumDataset", {schema_path_})) {
+    return false;
+  }
+
+  return true;
+}
+
+// Function to build AlbumDataset
+std::vector<std::shared_ptr<DatasetOp>> AlbumDataset::Build() {
+  // A vector containing shared pointer to the Dataset Ops that this object will create
+  std::vector<std::shared_ptr<DatasetOp>> node_ops;
+
+  // If user does not specify Sampler, create a default sampler, i.e., RandomSampler.
+  if (sampler_ == nullptr) {
+    sampler_ = CreateDefaultSampler();
+  }
+
+  auto schema = std::make_unique<DataSchema>();
+  RETURN_EMPTY_IF_ERROR(schema->LoadSchemaFile(schema_path_, column_names_));
+
+  // Argument that is not exposed to user in the API.
+  std::set<std::string> extensions = {};
+
+  node_ops.push_back(std::make_shared<AlbumOp>(num_workers_, rows_per_buffer_, dataset_dir_, connector_que_size_,
+                                               decode_, extensions, std::move(schema), std::move(sampler_->Build())));
+  return node_ops;
+}
+
 // Constructor for CelebADataset
 CelebADataset::CelebADataset(const std::string &dataset_dir, const std::string &dataset_type,
                              const std::shared_ptr<SamplerObj> &sampler, const bool &decode,

mindspore/ccsrc/minddata/dataset/engine/datasetops/source/CMakeLists.txt

@@ -13,6 +13,7 @@ set(DATASET_ENGINE_DATASETOPS_SOURCE_SRC_FILES
     text_file_op.cc
     clue_op.cc
     csv_op.cc
+    album_op.cc
     )

 set(DATASET_ENGINE_DATASETOPS_SOURCE_SRC_FILES

mindspore/ccsrc/minddata/dataset/engine/datasetops/source/album_op.cc

@@ -0,0 +1,508 @@
+/**
+ * Copyright 2020 Huawei Technologies Co., Ltd
+ *
+ * Licensed under the Apache License, Version 2.0 (the "License");
+ * you may not use this file except in compliance with the License.
+ * You may obtain a copy of the License at
+ *
+ * http://www.apache.org/licenses/LICENSE-2.0
+ *
+ * Unless required by applicable law or agreed to in writing, software
+ * distributed under the License is distributed on an "AS IS" BASIS,
+ * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+ * See the License for the specific language governing permissions and
+ * limitations under the License.
+ */
+#include "minddata/dataset/engine/datasetops/source/album_op.h"
+#include <fstream>
+#include <iomanip>
+#include "minddata/dataset/core/config_manager.h"
+#include "minddata/dataset/core/tensor_shape.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/sequential_sampler.h"
+#include "minddata/dataset/engine/db_connector.h"
+#include "minddata/dataset/engine/execution_tree.h"
+#include "minddata/dataset/engine/opt/pass.h"
+#include "minddata/dataset/kernels/image/image_utils.h"
+
+namespace mindspore {
+namespace dataset {
+AlbumOp::Builder::Builder() : builder_decode_(false), builder_sampler_(nullptr), builder_schema_file_("") {
+  std::shared_ptr<ConfigManager> cfg = GlobalContext::config_manager();
+  builder_num_workers_ = cfg->num_parallel_workers();
+  builder_rows_per_buffer_ = cfg->rows_per_buffer();
+  builder_op_connector_size_ = cfg->op_connector_size();
+}
+
+Status AlbumOp::Builder::Build(std::shared_ptr<AlbumOp> *ptr) {
+  RETURN_IF_NOT_OK(SanityCheck());
+  if (builder_sampler_ == nullptr) {
+    int64_t num_samples = 0;  // default num samples of 0 means to sample entire set of data
+    int64_t start_index = 0;
+    builder_sampler_ = std::make_shared<SequentialSampler>(start_index, num_samples);
+  }
+
+  builder_schema_ = std::make_unique<DataSchema>();
+  Path schema_file(builder_schema_file_);
+  if (builder_schema_file_ == "" || !schema_file.Exists()) {
+    RETURN_STATUS_UNEXPECTED("Schema not provided");
+  } else {
+    MS_LOG(INFO) << "Schema file provided: " << builder_schema_file_ << ".";
+    builder_schema_->LoadSchemaFile(builder_schema_file_, builder_columns_to_load_);
+  }
+  *ptr = std::make_shared<AlbumOp>(builder_num_workers_, builder_rows_per_buffer_, builder_dir_,
+                                   builder_op_connector_size_, builder_decode_, builder_extensions_,
+                                   std::move(builder_schema_), std::move(builder_sampler_));
+  return Status::OK();
+}
+
+Status AlbumOp::Builder::SanityCheck() {
+  Path dir(builder_dir_);
+  std::string err_msg;
+  err_msg += dir.IsDirectory() == false ? "Album path is invalid or not set\n" : "";
+  err_msg += builder_num_workers_ <= 0 ? "Num of parallel workers is set to 0\n" : "";
+  return err_msg.empty() ? Status::OK() : Status(StatusCode::kUnexpectedError, __LINE__, __FILE__, err_msg);
+}
+
+AlbumOp::AlbumOp(int32_t num_wkrs, int32_t rows_per_buffer, std::string file_dir, int32_t queue_size, bool do_decode,
+                 const std::set<std::string> &exts, std::unique_ptr<DataSchema> data_schema,
+                 std::shared_ptr<Sampler> sampler)
+    : ParallelOp(num_wkrs, queue_size),
+      rows_per_buffer_(rows_per_buffer),
+      folder_path_(file_dir),
+      decode_(do_decode),
+      extensions_(exts),
+      data_schema_(std::move(data_schema)),
+      sampler_(std::move(sampler)),
+      row_cnt_(0),
+      buf_cnt_(0),
+      sampler_ind_(0),
+      dirname_offset_(0) {
+  // Set the column name map (base class field)
+  for (int32_t i = 0; i < data_schema_->NumColumns(); ++i) {
+    column_name_id_map_[data_schema_->column(i).name()] = i;
+  }
+  io_block_queues_.Init(num_workers_, queue_size);
+}
+
+// Helper function for string comparison
+bool StrComp(const std::string &a, const std::string &b) {
+  // returns 1 if string a is alphabetically
+  // less than string b
+  // quite similar to strcmp operation
+  return a < b;
+}
+
+// Single thread to go through the folder directory and gets all file names
+// calculate numRows then return
+Status AlbumOp::PrescanEntry() {
+  Path folder(folder_path_);
+  dirname_offset_ = folder_path_.length();
+  std::shared_ptr<Path::DirIterator> dirItr = Path::DirIterator::OpenDirectory(&folder);
+  if (folder.Exists() == false || dirItr == nullptr) {
+    RETURN_STATUS_UNEXPECTED("Error unable to open: " + folder_path_);
+  }
+  MS_LOG(INFO) << "Album folder Path found: " << folder_path_ << ".";
+
+  while (dirItr->hasNext()) {
+    Path file = dirItr->next();
+    if (extensions_.empty() || extensions_.find(file.Extension()) != extensions_.end()) {
+      (void)image_rows_.push_back(file.toString().substr(dirname_offset_));
+    } else {
+      MS_LOG(INFO) << "Album operator unsupported file found: " << file.toString()
+                   << ", extension: " << file.Extension() << ".";
+    }
+  }
+
+  std::sort(image_rows_.begin(), image_rows_.end(), StrComp);
+  num_rows_ = image_rows_.size();
+  return Status::OK();
+}
+
+// Main logic, Register Queue with TaskGroup, launch all threads and do the functor's work
+Status AlbumOp::operator()() {
+  RETURN_IF_NOT_OK(this->PrescanEntry());
+  RETURN_IF_NOT_OK(LaunchThreadsAndInitOp());
+  std::unique_ptr<DataBuffer> sampler_buffer;
+  RETURN_IF_NOT_OK(sampler_->GetNextSample(&sampler_buffer));
+  while (true) {  // each iterator is 1 epoch
+    std::vector<int64_t> keys;
+    keys.reserve(rows_per_buffer_);
+    while (sampler_buffer->eoe() == false) {
+      TensorRow sample_row;
+      RETURN_IF_NOT_OK(sampler_buffer->PopRow(&sample_row));
+      std::shared_ptr<Tensor> sample_ids = sample_row[0];
+      for (auto itr = sample_ids->begin<int64_t>(); itr != sample_ids->end<int64_t>(); ++itr) {
+        if ((*itr) >= num_rows_) continue;  // index out of bound, skipping
+        keys.push_back(*itr);
+        row_cnt_++;
+        if (row_cnt_ % rows_per_buffer_ == 0) {
+          RETURN_IF_NOT_OK(
+            io_block_queues_[buf_cnt_++ % num_workers_]->Add(std::make_unique<IOBlock>(keys, IOBlock::kDeIoBlockNone)));
+          keys.clear();
+        }
+      }
+      RETURN_IF_NOT_OK(sampler_->GetNextSample(&sampler_buffer));
+    }
+    if (keys.empty() == false) {
+      RETURN_IF_NOT_OK(
+        io_block_queues_[(buf_cnt_++) % num_workers_]->Add(std::make_unique<IOBlock>(keys, IOBlock::kDeIoBlockNone)));
+    }
+    if (IsLastIteration()) {
+      std::unique_ptr<IOBlock> eoe_block = std::make_unique<IOBlock>(IOBlock::kDeIoBlockFlagEoe);
+      std::unique_ptr<IOBlock> eof_block = std::make_unique<IOBlock>(IOBlock::kDeIoBlockFlagEof);
+      RETURN_IF_NOT_OK(io_block_queues_[(buf_cnt_++) % num_workers_]->Add(std::move(eoe_block)));
+      RETURN_IF_NOT_OK(io_block_queues_[(buf_cnt_++) % num_workers_]->Add(std::move(eof_block)));
+      for (int32_t i = 0; i < num_workers_; ++i) {
+        RETURN_IF_NOT_OK(
+          io_block_queues_[i]->Add(std::make_unique<IOBlock>(std::vector<int64_t>(), IOBlock::kDeIoBlockNone)));
+      }
+      return Status::OK();
+    } else {  // not the last repeat. Sleep master thread, wait for the wake-up from reset
+      RETURN_IF_NOT_OK(
+        io_block_queues_[(buf_cnt_++) % num_workers_]->Add(std::make_unique<IOBlock>(IOBlock::kDeIoBlockFlagEoe)));
+      RETURN_IF_NOT_OK(wp_.Wait());  // Master thread goes to sleep after it has made all the IOBlocks
+      wp_.Clear();
+      RETURN_IF_NOT_OK(sampler_->GetNextSample(&sampler_buffer));
+    }
+    UpdateRepeatAndEpochCounter();
+  }
+}
+
+// contains the main logic of pulling a IOBlock from IOBlockQueue, load a buffer and push the buffer to out_connector_
+// IMPORTANT: 1 IOBlock produces 1 DataBuffer
+Status AlbumOp::WorkerEntry(int32_t worker_id) {
+  TaskManager::FindMe()->Post();
+  int64_t buffer_id = worker_id;
+  std::unique_ptr<IOBlock> io_block;
+  RETURN_IF_NOT_OK(io_block_queues_[worker_id]->PopFront(&io_block));
+  while (io_block != nullptr) {
+    if (io_block->eoe() == true) {
+      RETURN_IF_NOT_OK(out_connector_->Add(worker_id, std::make_unique<DataBuffer>(0, DataBuffer::kDeBFlagEOE)));
+      buffer_id = worker_id;
+    } else if (io_block->eof() == true) {
+      RETURN_IF_NOT_OK(out_connector_->Add(worker_id, std::make_unique<DataBuffer>(0, DataBuffer::kDeBFlagEOF)));
+    } else {
+      std::vector<int64_t> keys;
+      RETURN_IF_NOT_OK(io_block->GetKeys(&keys));
+      if (keys.empty() == true) return Status::OK();  // empty key is a quit signal for workers
+      std::unique_ptr<DataBuffer> db = std::make_unique<DataBuffer>(buffer_id, DataBuffer::kDeBFlagNone);
+      RETURN_IF_NOT_OK(LoadBuffer(keys, &db));
+      RETURN_IF_NOT_OK(out_connector_->Add(worker_id, std::move(db)));
+      buffer_id += num_workers_;
+    }
+    RETURN_IF_NOT_OK(io_block_queues_[worker_id]->PopFront(&io_block));
+  }
+  RETURN_STATUS_UNEXPECTED("Unexpected nullptr received in worker");
+}
+
+// Only support JPEG/PNG/GIF/BMP
+// Optimization: Could take in a tensor
+Status AlbumOp::CheckImageType(const std::string &file_name, bool *valid) {
+  std::ifstream file_handle;
+  constexpr int read_num = 3;
+  *valid = false;
+  file_handle.open(file_name, std::ios::binary | std::ios::in);
+  if (!file_handle.is_open()) {
+    RETURN_STATUS_UNEXPECTED("Can not open image file " + file_name);
+  }
+  unsigned char file_type[read_num];
+  (void)file_handle.read(reinterpret_cast<char *>(file_type), read_num);
+
+  if (file_handle.fail()) {
+    file_handle.close();
+    RETURN_STATUS_UNEXPECTED("Read image file failed " + file_name);
+  }
+  file_handle.close();
+  if (file_type[0] == 0xff && file_type[1] == 0xd8 && file_type[2] == 0xff) {
+    // Normal JPEGs start with \xff\xd8\xff\xe0
+    // JPEG with EXIF stats with \xff\xd8\xff\xe1
+    // Use \xff\xd8\xff to cover both.
+    *valid = true;
+  } else if (file_type[0] == 0x89 && file_type[1] == 0x50 && file_type[2] == 0x4e) {
+    // It's a PNG
+    *valid = true;
+  } else if (file_type[0] == 0x47 && file_type[1] == 0x49 && file_type[2] == 0x46) {
+    // It's a GIF
+    *valid = true;
+  } else if (file_type[0] == 0x42 && file_type[1] == 0x4d) {
+    // It's a BMP
+    *valid = true;
+  }
+  return Status::OK();
+}
+
+Status AlbumOp::LoadImageTensor(const std::string &image_file_path, uint32_t col_num, TensorRow *row) {
+  std::shared_ptr<Tensor> image;
+  std::ifstream fs;
+  fs.open(image_file_path, std::ios::binary | std::ios::in);
+  if (fs.fail()) {
+    MS_LOG(INFO) << "Image file not found:" << image_file_path << ".";
+    // If file doesn't exist, we don't flag this as error in input check, simply skip
+    return Status::OK();
+  }
+
+  MS_LOG(INFO) << "Image file found: " << image_file_path << ".";
+
+  // check that the file is an image before decoding
+  bool valid = false;
+  RETURN_IF_NOT_OK(CheckImageType(image_file_path, &valid));
+  RETURN_IF_NOT_OK(Tensor::CreateFromFile(image_file_path, &image));
+  if (decode_ && valid) {
+    Status rc = Decode(image, &image);
+    if (rc.IsError()) {
+      std::string err = "Fail to decode image:" + image_file_path;
+      RETURN_STATUS_UNEXPECTED(err);
+    }
+  }
+  row->push_back(std::move(image));
+  return Status::OK();
+}
+
+Status AlbumOp::LoadStringArrayTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row) {
+  std::vector<std::string> data = json_obj;
+
+  MS_LOG(INFO) << "String array label found: " << data << ".";
+  std::shared_ptr<Tensor> label;
+  RETURN_IF_NOT_OK(Tensor::CreateFromVector(data, &label));
+  row->push_back(std::move(label));
+  return Status::OK();
+}
+
+Status AlbumOp::LoadStringTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row) {
+  std::string data = json_obj;
+  // now we iterate over the elements in json
+
+  MS_LOG(INFO) << "String label found: " << data << ".";
+  std::shared_ptr<Tensor> label;
+  RETURN_IF_NOT_OK(Tensor::CreateScalar<std::string>(data, &label));
+  row->push_back(std::move(label));
+  return Status::OK();
+}
+
+Status AlbumOp::LoadIntArrayTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row) {
+  std::shared_ptr<Tensor> label;
+  // consider templating this function to handle all ints
+  if (data_schema_->column(col_num).type() == DataType(DataType::DE_INT64)) {
+    std::vector<int64_t> data;
+
+    // Iterate over the integer list and add those values to the output shape tensor
+    auto items = json_obj.items();
+    using it_type = decltype(items.begin());
+    (void)std::transform(items.begin(), items.end(), std::back_inserter(data), [](it_type j) { return j.value(); });
+
+    RETURN_IF_NOT_OK(Tensor::CreateFromVector(data, &label));
+  } else if (data_schema_->column(col_num).type() == DataType(DataType::DE_INT32)) {
+    std::vector<int32_t> data;
+
+    // Iterate over the integer list and add those values to the output shape tensor
+    auto items = json_obj.items();
+    using it_type = decltype(items.begin());
+    (void)std::transform(items.begin(), items.end(), std::back_inserter(data), [](it_type j) { return j.value(); });
+
+    MS_LOG(INFO) << "Int array found: " << data << ".";
+    RETURN_IF_NOT_OK(Tensor::CreateFromVector(data, &label));
+  } else {
+    RETURN_STATUS_UNEXPECTED("Error in Load Int Tensor");
+  }
+  row->push_back(std::move(label));
+  return Status::OK();
+}
+
+Status AlbumOp::LoadIDTensor(const std::string &file, uint32_t col_num, TensorRow *row) {
+  if (data_schema_->column(col_num).type() == DataType(DataType::DE_STRING)) {
+    std::shared_ptr<Tensor> id;
+    RETURN_IF_NOT_OK(Tensor::CreateScalar<std::string>(file, &id));
+    row->push_back(std::move(id));
+    return Status::OK();
+  }
+  // hack to get the file name without extension, the 1 is to get rid of the backslash character
+  int64_t image_id = std::atoi(file.substr(1, file.find(".")).c_str());
+  std::shared_ptr<Tensor> id;
+  RETURN_IF_NOT_OK(Tensor::CreateScalar<int64_t>(image_id, &id));
+  MS_LOG(INFO) << "File ID " << image_id << ".";
+  row->push_back(std::move(id));
+  return Status::OK();
+}
+
+Status AlbumOp::LoadEmptyTensor(uint32_t col_num, TensorRow *row) {
+  // hack to get the file name without extension, the 1 is to get rid of the backslash character
+  std::shared_ptr<Tensor> empty_tensor;
+  RETURN_IF_NOT_OK(Tensor::CreateEmpty(TensorShape({}), data_schema_->column(col_num).type(), &empty_tensor));
+  row->push_back(std::move(empty_tensor));
+  return Status::OK();
+}
+
+// Loads a tensor with float value, issue with float64, we don't have reverse look up to the type
+// So we actually have to check what type we want to fill the tensor with.
+// Float64 doesn't work with reinterpret cast here. Otherwise we limit the float in the schema to
+// only be float32, seems like a weird limitation to impose
+Status AlbumOp::LoadFloatTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row) {
+  std::shared_ptr<Tensor> float_tensor;
+  if (data_schema_->column(col_num).type() == DataType(DataType::DE_FLOAT64)) {
+    double data = json_obj;
+    MS_LOG(INFO) << "double found: " << json_obj << ".";
+    RETURN_IF_NOT_OK(Tensor::CreateScalar<double>(data, &float_tensor));
+  } else if (data_schema_->column(col_num).type() == DataType(DataType::DE_FLOAT32)) {
+    float data = json_obj;
+    RETURN_IF_NOT_OK(Tensor::CreateScalar<float>(data, &float_tensor));
+    MS_LOG(INFO) << "float found: " << json_obj << ".";
+  }
+  row->push_back(std::move(float_tensor));
+  return Status::OK();
+}
+
+// Load 1 TensorRow (image,label) using 1 ImageColumns. 1 function call produces 1 TensorTow in a DataBuffer
+// possible optimization: the helper functions of LoadTensorRow should be optimized
+// to take a reference to a column descriptor?
+Status AlbumOp::LoadTensorRow(const std::string &file, TensorRow *row) {
+  // testing here is to just print out file path
+  (*row) = {};
+  MS_LOG(INFO) << "Image row file: " << file << ".";
+
+  std::ifstream file_handle(folder_path_ + file);
+  if (!file_handle.is_open()) {
+    RETURN_STATUS_UNEXPECTED("Json file " + folder_path_ + file + " can not open.");
+  }
+  std::string line;
+  while (getline(file_handle, line)) {
+    try {
+      nlohmann::json js = nlohmann::json::parse(line);
+      MS_LOG(INFO) << "This Line: " << line << ".";
+
+      // note if take a schema here, then we have to iterate over all column descriptors in schema and check for key
+      // get columns in schema:
+      int32_t columns = data_schema_->NumColumns();
+
+      // loop over each column descriptor, this can optimized by swtich cases
+      for (int32_t i = 0; i < columns; i++) {
+        // special case to handle
+        if (data_schema_->column(i).name() == "id") {
+          // id is internal, special case to load from file
+          RETURN_IF_NOT_OK(LoadIDTensor(file, i, row));
+          continue;
+        }
+        // find if key does not exist, insert placeholder nullptr if not found
+        if (js.find(data_schema_->column(i).name()) == js.end()) {
+          // iterator not found, push nullptr as placeholder
+          MS_LOG(INFO) << "Pushing empty tensor for column: " << data_schema_->column(i).name() << ".";
+          RETURN_IF_NOT_OK(LoadEmptyTensor(i, row));
+          continue;
+        }
+        nlohmann::json column_value = js.at(data_schema_->column(i).name());
+        MS_LOG(INFO) << "This column is: " << data_schema_->column(i).name() << ".";
+        bool is_array = column_value.is_array();
+        // load single string
+        if (column_value.is_string() && data_schema_->column(i).type() == DataType(DataType::DE_STRING)) {
+          RETURN_IF_NOT_OK(LoadStringTensor(column_value, i, row));
+          continue;
+        }
+        // load string array
+        if (is_array && data_schema_->column(i).type() == DataType(DataType::DE_STRING)) {
+          RETURN_IF_NOT_OK(LoadStringArrayTensor(column_value, i, row));
+          continue;
+        }
+        // load image file
+        if (column_value.is_string() && data_schema_->column(i).type() != DataType(DataType::DE_STRING)) {
+          std::string image_file_path = column_value;
+          RETURN_IF_NOT_OK(LoadImageTensor(image_file_path, i, row));
+          continue;
+        }
+        // load float array
+        if (!is_array && (data_schema_->column(i).type() == DataType(DataType::DE_FLOAT32) ||
+                          data_schema_->column(i).type() == DataType(DataType::DE_FLOAT64))) {
+          RETURN_IF_NOT_OK(LoadFloatTensor(column_value, i, row));
+          continue;
+        }
+        // int array
+        if (is_array && (data_schema_->column(i).type() == DataType(DataType::DE_INT64) ||
+                         data_schema_->column(i).type() == DataType(DataType::DE_INT32))) {
+          RETURN_IF_NOT_OK(LoadIntArrayTensor(column_value, i, row));
+          continue;
+        } else {
+          MS_LOG(WARNING) << "Value type for column: " << data_schema_->column(i).name() << " is not supported.";
+          continue;
+        }
+      }
+    } catch (const std::exception &err) {
+      file_handle.close();
+      RETURN_STATUS_UNEXPECTED("Parse Json file failed");
+    }
+  }
+  file_handle.close();
+  return Status::OK();
+}
+
+// Looping over LoadTensorRow to make 1 DataBuffer. 1 function call produces 1 buffer
+Status AlbumOp::LoadBuffer(const std::vector<int64_t> &keys, std::unique_ptr<DataBuffer> *db) {
+  std::unique_ptr<TensorQTable> deq = std::make_unique<TensorQTable>();
+  TensorRow trow;
+
+  for (const int64_t &key : keys) {
+    RETURN_IF_NOT_OK(this->LoadTensorRow(image_rows_[key], &trow));
+    deq->push_back(std::move(trow));
+  }
+  (*db)->set_tensor_table(std::move(deq));
+  return Status::OK();
+}
+
+void AlbumOp::Print(std::ostream &out, bool show_all) const {
+  // Always show the id and name as first line regardless if this summary or detailed print
+  out << "(" << std::setw(2) << operator_id_ << ") <AlbumOp>:";
+  if (!show_all) {
+    // Call the super class for displaying any common 1-liner info
+    ParallelOp::Print(out, show_all);
+    // Then show any custom derived-internal 1-liner info for this op
+    out << "\n";
+  } else {
+    // Call the super class for displaying any common detailed info
+    ParallelOp::Print(out, show_all);
+    // Then show any custom derived-internal stuff
+    out << "\nNumber of rows:" << num_rows_ << "\nAlbum directory: " << folder_path_ << "\n\n";
+  }
+}
+
+// Reset Sampler and wakeup Master thread (functor)
+Status AlbumOp::Reset() {
+  RETURN_IF_NOT_OK(sampler_->ResetSampler());
+  row_cnt_ = 0;
+  wp_.Set();  // wake up master thread after reset is done
+  return Status::OK();
+}
+
+// hand shake with Sampler, allow Sampler to call RandomAccessOp's functions to get NumRows
+Status AlbumOp::InitSampler() {
+  RETURN_IF_NOT_OK(sampler_->HandshakeRandomAccessOp(this));
+  return Status::OK();
+}
+
+Status AlbumOp::LaunchThreadsAndInitOp() {
+  RETURN_UNEXPECTED_IF_NULL(tree_);
+  // registers QueueList and individual Queues for interrupt services
+  RETURN_IF_NOT_OK(io_block_queues_.Register(tree_->AllTasks()));
+  RETURN_IF_NOT_OK(wp_.Register(tree_->AllTasks()));
+  // launch main workers that load DataBuffers by reading all images
+  RETURN_IF_NOT_OK(tree_->LaunchWorkers(num_workers_, std::bind(&AlbumOp::WorkerEntry, this, std::placeholders::_1)));
+  TaskManager::FindMe()->Post();
+  RETURN_IF_NOT_OK(this->InitSampler());  // pass numRows to Sampler
+  return Status::OK();
+}
+
+// Visitor accept method for NodePass
+Status AlbumOp::Accept(NodePass *p, bool *modified) {
+  // Downcast shared pointer then call visitor
+  return p->RunOnNode(shared_from_base<AlbumOp>(), modified);
+}
+
+Status AlbumOp::ComputeColMap() {
+  // Set the column name map (base class field)
+  if (column_name_id_map_.empty()) {
+    for (int32_t i = 0; i < data_schema_->NumColumns(); ++i) {
+      column_name_id_map_[data_schema_->column(i).name()] = i;
+    }
+  } else {
+    MS_LOG(WARNING) << "Column name map is already set!";
+  }
+  return Status::OK();
+}
+}  // namespace dataset
+}  // namespace mindspore

mindspore/ccsrc/minddata/dataset/engine/datasetops/source/album_op.h

@@ -0,0 +1,298 @@
+/**
+ * Copyright 2020 Huawei Technologies Co., Ltd
+ *
+ * Licensed under the Apache License, Version 2.0 (the "License");
+ * you may not use this file except in compliance with the License.
+ * You may obtain a copy of the License at
+ *
+ * http://www.apache.org/licenses/LICENSE-2.0
+ *
+ * Unless required by applicable law or agreed to in writing, software
+ * distributed under the License is distributed on an "AS IS" BASIS,
+ * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+ * See the License for the specific language governing permissions and
+ * limitations under the License.
+ */
+#ifndef MINDSPORE_CCSRC_MINDDATA_DATASET_ENGINE_DATASETOPS_SOURCE_ALBUM_OP_H_
+#define MINDSPORE_CCSRC_MINDDATA_DATASET_ENGINE_DATASETOPS_SOURCE_ALBUM_OP_H_
+
+#include <deque>
+#include <memory>
+#include <queue>
+#include <string>
+#include <algorithm>
+#include <map>
+#include <set>
+#include <utility>
+#include <vector>
+#include <unordered_map>
+#include "minddata/dataset/core/tensor.h"
+#include "minddata/dataset/engine/data_buffer.h"
+#include "minddata/dataset/engine/data_schema.h"
+#include "minddata/dataset/engine/datasetops/parallel_op.h"
+#include "minddata/dataset/engine/datasetops/source/io_block.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/sampler.h"
+#include "minddata/dataset/util/path.h"
+#include "minddata/dataset/util/queue.h"
+#include "minddata/dataset/util/services.h"
+#include "minddata/dataset/util/status.h"
+#include "minddata/dataset/util/wait_post.h"
+
+namespace mindspore {
+namespace dataset {
+// Forward declares
+template <typename T>
+class Queue;
+
+// Define row information as a list of file objects to read
+using FolderImages = std::shared_ptr<std::pair<std::string, std::queue<std::string>>>;
+
+/// \class AlbumOp album_op.h
+class AlbumOp : public ParallelOp, public RandomAccessOp {
+ public:
+  class Builder {
+   public:
+    /// \brief Constructor for Builder class of AlbumOp
+    Builder();
+
+    /// \brief Destructor.
+    ~Builder() = default;
+
+    /// \brief Setter method
+    /// \param[in] rows_per_buffer
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetRowsPerBuffer(int32_t rows_per_buffer) {
+      builder_rows_per_buffer_ = rows_per_buffer;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] size
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetOpConnectorSize(int32_t size) {
+      builder_op_connector_size_ = size;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] exts - file extensions to be read
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetExtensions(const std::set<std::string> &exts) {
+      builder_extensions_ = exts;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] do_decode
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetDecode(bool do_decode) {
+      builder_decode_ = do_decode;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] num_workers
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetNumWorkers(int32_t num_workers) {
+      builder_num_workers_ = num_workers;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] sampler
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetSampler(std::shared_ptr<Sampler> sampler) {
+      builder_sampler_ = std::move(sampler);
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] dir - dataset directory
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetAlbumDir(const std::string &dir) {
+      builder_dir_ = dir;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] file - schema file to load
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetSchemaFile(const std::string &file) {
+      builder_schema_file_ = file;
+      return *this;
+    }
+
+    /// \brief Setter method
+    /// \param[in] columns - input columns
+    /// \return Builder setter method returns reference to the builder
+    Builder &SetColumnsToLoad(const std::vector<std::string> &columns) {
+      builder_columns_to_load_ = columns;
+      return *this;
+    }
+
+    /// \brief Check validity of input args
+    /// \return - The error code return
+    Status SanityCheck();
+
+    /// \brief The builder "build" method creates the final object.
+    /// \param[inout] std::shared_ptr<AlbumOp> *op - DatasetOp
+    /// \return - The error code return
+    Status Build(std::shared_ptr<AlbumOp> *op);
+
+   private:
+    bool builder_decode_;
+    std::vector<std::string> builder_columns_to_load_;
+    std::string builder_dir_;
+    std::string builder_schema_file_;
+    int32_t builder_num_workers_;
+    int32_t builder_rows_per_buffer_;
+    int32_t builder_op_connector_size_;
+    std::set<std::string> builder_extensions_;
+    std::shared_ptr<Sampler> builder_sampler_;
+    std::unique_ptr<DataSchema> builder_schema_;
+  };
+
+  /// \brief Constructor
+  /// \param[in] num_wkrs - Num of workers reading images in parallel
+  /// \param[in] rows_per_buffer Number of images (rows) in each buffer
+  /// \param[in] file_dir - directory of Album
+  /// \param[in] queue_size - connector size
+  /// \param[in] do_decode - decode image files
+  /// \param[in] exts - set of file extensions to read, if empty, read everything under the dir
+  /// \param[in] data_schema - schema of dataset
+  /// \param[in] sampler - sampler tells AlbumOp what to read
+  AlbumOp(int32_t num_wkrs, int32_t rows_per_buffer, std::string file_dir, int32_t queue_size, bool do_decode,
+          const std::set<std::string> &exts, std::unique_ptr<DataSchema> data_schema, std::shared_ptr<Sampler> sampler);
+
+  /// \brief Destructor.
+  ~AlbumOp() = default;
+
+  /// \brief Initialize AlbumOp related var, calls the function to walk all files
+  /// \return - The error code return
+  Status PrescanEntry();
+
+  /// \brief Worker thread pulls a number of IOBlock from IOBlock Queue, make a buffer and push it to Connector
+  /// \param[in] int32_t workerId - id of each worker
+  /// \return Status - The error code return
+  Status WorkerEntry(int32_t worker_id) override;
+
+  /// \brief Main Loop of AlbumOp
+  ///     Master thread: Fill IOBlockQueue, then goes to sleep
+  ///     Worker thread: pulls IOBlock from IOBlockQueue, work on it then put buffer to mOutConnector
+  /// \return Status - The error code return
+  Status operator()() override;
+
+  /// \brief A print method typically used for debugging
+  /// \param[in] out
+  /// \param[in] show_all
+  void Print(std::ostream &out, bool show_all) const override;
+
+  /// \brief Check if image ia valid.Only support JPEG/PNG/GIF/BMP
+  ///     This function could be optimized to return the tensor to reduce open/closing files
+  /// \return Status - The error code return
+  Status CheckImageType(const std::string &file_name, bool *valid);
+
+  // Base-class override for NodePass visitor acceptor.
+  // @param p - Pointer to the NodePass to be accepted.
+  // @param modified - Whether this node visit modified the pipeline.
+  // @return - Status of the node visit.
+  Status Accept(NodePass *p, bool *modified) override;
+
+  // Op name getter
+  // @return Name of the current Op
+  std::string Name() const override { return "AlbumOp"; }
+
+ private:
+  /// \brief Initialize Sampler, calls sampler->Init() within
+  /// \return Status The error code return
+  Status InitSampler();
+
+  /// \brief Load image to tensor row
+  /// \param[in] image_file Image name of file
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadImageTensor(const std::string &image_file, uint32_t col_num, TensorRow *row);
+
+  /// \brief Load vector of ints to tensor, append tensor to tensor row
+  /// \param[in] json_obj Json object containing multi-dimensional label
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadIntArrayTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row);
+
+  /// \brief Load string array into a tensor, append tensor to tensor row
+  /// \param[in] json_obj Json object containing string tensor
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadStringArrayTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row);
+
+  /// \brief Load string into a tensor, append tensor to tensor row
+  /// \param[in] json_obj Json object containing string tensor
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadStringTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row);
+
+  /// \brief Load float value to tensor row
+  /// \param[in] json_obj Json object containing float
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadFloatTensor(const nlohmann::json &json_obj, uint32_t col_num, TensorRow *row);
+
+  /// \brief Load emtpy tensor to tensor row
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadEmptyTensor(uint32_t col_num, TensorRow *row);
+
+  /// \brief Load id from file name to tensor row
+  /// \param[in] file The file name to get ID from
+  /// \param[in] col_num Column num in schema
+  /// \param[inout] row Tensor row to push to
+  /// \return Status The error code return
+  Status LoadIDTensor(const std::string &file, uint32_t col_num, TensorRow *row);
+
+  /// \brief Load a tensor row according to a json file
+  /// \param[in] ImageColumns file Json file location
+  /// \param[inout] TensorRow row Json content stored into a tensor row
+  /// \return Status The error code return
+  Status LoadTensorRow(const std::string &file, TensorRow *row);
+
+  /// \param[in] const std::vector<int64_t> &keys Keys in ioblock
+  /// \param[inout] std::unique_ptr<DataBuffer> db Databuffer to push to
+  /// \return Status The error code return
+  Status LoadBuffer(const std::vector<int64_t> &keys, std::unique_ptr<DataBuffer> *db);
+
+  /// \brief Called first when function is called
+  /// \return The error code return
+  Status LaunchThreadsAndInitOp();
+
+  /// \brief reset Op
+  /// \return Status The error code return
+  Status Reset() override;
+
+  // Private function for computing the assignment of the column name map.
+  // @return - Status
+  Status ComputeColMap() override;
+
+  int32_t rows_per_buffer_;
+  std::string folder_path_;  // directory of image folder
+  bool decode_;
+  std::set<std::string> extensions_;  // extensions allowed
+  std::unordered_map<std::string, int32_t> col_name_map_;
+  std::unique_ptr<DataSchema> data_schema_;
+  std::shared_ptr<Sampler> sampler_;
+  int64_t row_cnt_;
+  int64_t buf_cnt_;
+  int64_t sampler_ind_;
+  int64_t dirname_offset_;
+  WaitPost wp_;
+  std::vector<std::string> image_rows_;
+  QueueList<std::unique_ptr<IOBlock>> io_block_queues_;  // queues of IOBlocks
+};
+}  // namespace dataset
+}  // namespace mindspore
+#endif  // MINDSPORE_CCSRC_MINDDATA_DATASET_ENGINE_DATASETOPS_SOURCE_ALBUM_OP_H_

mindspore/ccsrc/minddata/dataset/engine/datasetops/source/image_folder_op.cc

@@ -134,7 +134,6 @@ Status ImageFolderOp::operator()() {
       TensorRow sample_row;
       RETURN_IF_NOT_OK(sampler_buffer->PopRow(&sample_row));
       std::shared_ptr<Tensor> sample_ids = sample_row[0];
-      if (sample_ids->type() != DataType(DataType::DE_INT64)) RETURN_STATUS_UNEXPECTED("Sampler Tensor isn't int64");
       for (auto itr = sample_ids->begin<int64_t>(); itr != sample_ids->end<int64_t>(); ++itr) {
         if ((*itr) >= num_rows_) continue;  // index out of bound, skipping
         keys.push_back(*itr);

mindspore/ccsrc/minddata/dataset/engine/opt/pass.cc

@@ -30,6 +30,7 @@
 #include "minddata/dataset/engine/datasetops/repeat_op.h"
 #include "minddata/dataset/engine/datasetops/skip_op.h"
 #include "minddata/dataset/engine/datasetops/shuffle_op.h"
+#include "minddata/dataset/engine/datasetops/source/album_op.h"
 #include "minddata/dataset/engine/datasetops/source/celeba_op.h"
 #include "minddata/dataset/engine/datasetops/source/cifar_op.h"
 #include "minddata/dataset/engine/datasetops/source/coco_op.h"
@@ -199,6 +200,11 @@ Status NodePass::RunOnNode(std::shared_ptr<ImageFolderOp> node, bool *modified)
   return RunOnNode(std::static_pointer_cast<DatasetOp>(node), modified);
 }

+Status NodePass::RunOnNode(std::shared_ptr<AlbumOp> node, bool *modified) {
+  // Fallback to base class visitor by default
+  return RunOnNode(std::static_pointer_cast<DatasetOp>(node), modified);
+}
+
 Status NodePass::RunOnNode(std::shared_ptr<CacheOp> node, bool *modified) {
   // Fallback to base class visitor by default
   return RunOnNode(std::static_pointer_cast<DatasetOp>(node), modified);

mindspore/ccsrc/minddata/dataset/engine/opt/pass.h

@@ -49,6 +49,8 @@ class FilterOp;
 class GeneratorOp;
 #endif

+class AlbumOp;
+
 class RandomDataOp;

 class RepeatOp;
@@ -178,6 +180,8 @@ class NodePass : public Pass {

   virtual Status RunOnNode(std::shared_ptr<RandomDataOp> node, bool *modified);

+  virtual Status RunOnNode(std::shared_ptr<AlbumOp> node, bool *modified);
+
   virtual Status RunOnNode(std::shared_ptr<TakeOp> node, bool *modified);

   virtual Status RunOnNode(std::shared_ptr<ZipOp> node, bool *modified);

mindspore/ccsrc/minddata/dataset/engine/opt/pre/cache_transform_pass.cc

@@ -21,6 +21,7 @@
 #include "minddata/dataset/engine/datasetops/cache_lookup_op.h"
 #include "minddata/dataset/engine/datasetops/cache_merge_op.h"
 #include "minddata/dataset/engine/datasetops/cache_op.h"
+#include "minddata/dataset/engine/datasetops/source/album_op.h"
 #include "minddata/dataset/engine/datasetops/source/celeba_op.h"
 #include "minddata/dataset/engine/datasetops/source/cifar_op.h"
 #include "minddata/dataset/engine/datasetops/source/coco_op.h"
@@ -152,6 +153,11 @@ Status CacheTransformPass::CachePass::RunOnNode(std::shared_ptr<ImageFolderOp> n
   return MappableCacheLeafSetup(std::static_pointer_cast<DatasetOp>(node));
 }

+// Perform leaf node cache transform identification
+Status CacheTransformPass::CachePass::RunOnNode(std::shared_ptr<AlbumOp> node, bool *modified) {
+  return MappableCacheLeafSetup(std::static_pointer_cast<DatasetOp>(node));
+}
+
 // Perform leaf node cache transform identification
 Status CacheTransformPass::CachePass::RunOnNode(std::shared_ptr<MnistOp> node, bool *modified) {
   return MappableCacheLeafSetup(std::static_pointer_cast<DatasetOp>(node));

mindspore/ccsrc/minddata/dataset/engine/opt/pre/cache_transform_pass.h

@@ -79,6 +79,12 @@ class CacheTransformPass : public TreePass {
     /// \return Status The error code return
     Status RunOnNode(std::shared_ptr<ImageFolderOp> node, bool *modified) override;

+    /// \brief Perform leaf node cache tranform identifications
+    /// \param[in] node The node being visited
+    /// \param[inout] modified Indicator if the node was changed at all
+    /// \return Status The error code return
+    Status RunOnNode(std::shared_ptr<AlbumOp> node, bool *modified) override;
+
     /// \brief Perform leaf node cache tranform identifications
     /// \param[in] node The node being visited
     /// \param[inout] modified Indicator if the node was changed at all

mindspore/ccsrc/minddata/dataset/engine/opt/util/printer_pass.cc

@@ -111,5 +111,11 @@ Status PrinterPass::RunOnNode(std::shared_ptr<ImageFolderOp> node, bool *modifie
   std::cout << "Visiting ImageFolderOp" << '\n';
   return Status::OK();
 }
+
+Status PrinterPass::RunOnNode(std::shared_ptr<AlbumOp> node, bool *modified) {
+  *modified = false;
+  std::cout << "Visiting ImageFolderOp" << '\n';
+  return Status::OK();
+}
 }  // namespace dataset
 }  // namespace mindspore

mindspore/ccsrc/minddata/dataset/engine/opt/util/printer_pass.h

@@ -58,6 +58,8 @@ class PrinterPass : public NodePass {
   Status RunOnNode(std::shared_ptr<DeviceQueueOp> node, bool *modified) override;

   Status RunOnNode(std::shared_ptr<ImageFolderOp> node, bool *modified) override;
+
+  Status RunOnNode(std::shared_ptr<AlbumOp> node, bool *modified) override;
 };

 }  // namespace dataset

mindspore/ccsrc/minddata/dataset/include/datasets.h

@@ -48,6 +48,7 @@ class TensorOperation;
 class SchemaObj;
 class SamplerObj;
 // Datasets classes (in alphabetical order)
+class AlbumDataset;
 class CelebADataset;
 class Cifar10Dataset;
 class Cifar100Dataset;
@@ -79,13 +80,27 @@ class ZipDataset;
 /// \return Shared pointer to the current schema
 std::shared_ptr<SchemaObj> Schema(const std::string &schema_file = "");

+/// \brief Function to create an AlbumDataset
+/// \notes The generated dataset is specified through setting a schema
+/// \param[in] dataset_dir Path to the root directory that contains the dataset
+/// \param[in] data_schema Path to dataset schema file
+/// \param[in] column_names Column names used to specify columns to load, if empty, will read all columns.
+///     (default = {})
+/// \param[in] decode the option to decode the images in dataset (default = false)
+/// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`,
+///     A `RandomSampler` will be used to randomly iterate the entire dataset (default = nullptr)
+/// \return Shared pointer to the current Dataset
+std::shared_ptr<AlbumDataset> Album(const std::string &dataset_dir, const std::string &data_schema,
+                                    const std::vector<std::string> &column_names = {}, bool decode = false,
+                                    const std::shared_ptr<SamplerObj> &sampler = nullptr);
+
 /// \brief Function to create a CelebADataset
 /// \notes The generated dataset has two columns ['image', 'attr'].
-//     The type of the image tensor is uint8. The attr tensor is uint32 and one hot type.
+//      The type of the image tensor is uint8. The attr tensor is uint32 and one hot type.
 /// \param[in] dataset_dir Path to the root directory that contains the dataset.
 /// \param[in] dataset_type One of 'all', 'train', 'valid' or 'test'.
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`, A `RandomSampler`
-///    will be used to randomly iterate the entire dataset
+///     will be used to randomly iterate the entire dataset
 /// \param[in] decode Decode the images after reading (default=false).
 /// \param[in] extensions Set of file extensions to be included in the dataset (default={}).
 /// \return Shared pointer to the current Dataset
@@ -97,7 +112,7 @@ std::shared_ptr<CelebADataset> CelebA(const std::string &dataset_dir, const std:
 /// \notes The generated dataset has two columns ['image', 'label']
 /// \param[in] dataset_dir Path to the root directory that contains the dataset
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`, A `RandomSampler`
-///    will be used to randomly iterate the entire dataset
+///     will be used to randomly iterate the entire dataset
 /// \return Shared pointer to the current Dataset
 std::shared_ptr<Cifar10Dataset> Cifar10(const std::string &dataset_dir,
                                         const std::shared_ptr<SamplerObj> &sampler = nullptr);
@@ -106,7 +121,7 @@ std::shared_ptr<Cifar10Dataset> Cifar10(const std::string &dataset_dir,
 /// \notes The generated dataset has three columns ['image', 'coarse_label', 'fine_label']
 /// \param[in] dataset_dir Path to the root directory that contains the dataset
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`, A `RandomSampler`
-///    will be used to randomly iterate the entire dataset
+///     will be used to randomly iterate the entire dataset
 /// \return Shared pointer to the current Dataset
 std::shared_ptr<Cifar100Dataset> Cifar100(const std::string &dataset_dir,
                                           const std::shared_ptr<SamplerObj> &sampler = nullptr);
@@ -114,19 +129,19 @@ std::shared_ptr<Cifar100Dataset> Cifar100(const std::string &dataset_dir,
 /// \brief Function to create a CLUEDataset
 /// \notes The generated dataset has a variable number of columns depending on the task and usage
 /// \param[in] dataset_files List of files to be read to search for a pattern of files. The list
-///    will be sorted in a lexicographical order.
+///     will be sorted in a lexicographical order.
 /// \param[in] task The kind of task, one of "AFQMC", "TNEWS", "IFLYTEK", "CMNLI", "WSC" and "CSL" (default="AFQMC").
 /// \param[in] usage Be used to "train", "test" or "eval" data (default="train").
 /// \param[in] num_samples The number of samples to be included in the dataset.
-///    (Default = 0 means all samples.)
-/// \param[in] shuffle The mode for shuffling data every epoch. (Default=ShuffleMode::kGlobal)
-///    Can be any of:
-///    ShuffleMode::kFalse - No shuffling is performed.
-///    ShuffleMode::kFiles - Shuffle files only.
-///    ShuffleMode::kGlobal - Shuffle both the files and samples.
+///     (Default = 0 means all samples.)
+/// \param[in] shuffle The mode for shuffling data every epoch. (Default=ShuffleMode.kGlobal)
+///     Can be any of:
+///     ShuffleMode.kFalse - No shuffling is performed.
+///     ShuffleMode.kFiles - Shuffle files only.
+///     ShuffleMode.kGlobal - Shuffle both the files and samples.
 /// \param[in] num_shards Number of shards that the dataset should be divided into. (Default = 1)
 /// \param[in] shard_id The shard ID within num_shards. This argument should be
-///    specified only when num_shards is also specified. (Default = 0)
+///     specified only when num_shards is also specified. (Default = 0)
 /// \return Shared pointer to the current CLUEDataset
 std::shared_ptr<CLUEDataset> CLUE(const std::vector<std::string> &dataset_files, const std::string &task = "AFQMC",
                                   const std::string &usage = "train", int64_t num_samples = 0,
@@ -135,19 +150,19 @@ std::shared_ptr<CLUEDataset> CLUE(const std::vector<std::string> &dataset_files,

 /// \brief Function to create a CocoDataset
 /// \notes The generated dataset has multi-columns :
-///        - task='Detection', column: [['image', dtype=uint8], ['bbox', dtype=float32], ['category_id', dtype=uint32],
-///                                     ['iscrowd', dtype=uint32]].
-///        - task='Stuff', column: [['image', dtype=uint8], ['segmentation',dtype=float32], ['iscrowd', dtype=uint32]].
-///        - task='Keypoint', column: [['image', dtype=uint8], ['keypoints', dtype=float32],
-///                                    ['num_keypoints', dtype=uint32]].
-///        - task='Panoptic', column: [['image', dtype=uint8], ['bbox', dtype=float32], ['category_id', dtype=uint32],
-///                                    ['iscrowd', dtype=uint32], ['area', dtype=uitn32]].
+///     - task='Detection', column: [['image', dtype=uint8], ['bbox', dtype=float32], ['category_id', dtype=uint32],
+///                                  ['iscrowd', dtype=uint32]].
+///     - task='Stuff', column: [['image', dtype=uint8], ['segmentation',dtype=float32], ['iscrowd', dtype=uint32]].
+///     - task='Keypoint', column: [['image', dtype=uint8], ['keypoints', dtype=float32],
+///                                 ['num_keypoints', dtype=uint32]].
+///     - task='Panoptic', column: [['image', dtype=uint8], ['bbox', dtype=float32], ['category_id', dtype=uint32],
+///                                 ['iscrowd', dtype=uint32], ['area', dtype=uitn32]].
 /// \param[in] dataset_dir Path to the root directory that contains the dataset
 /// \param[in] annotation_file Path to the annotation json
 /// \param[in] task Set the task type of reading coco data, now support 'Detection'/'Stuff'/'Panoptic'/'Keypoint'
 /// \param[in] decode Decode the images after reading
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`, A `RandomSampler`
-///    will be used to randomly iterate the entire dataset
+///     will be used to randomly iterate the entire dataset
 /// \return Shared pointer to the current Dataset
 std::shared_ptr<CocoDataset> Coco(const std::string &dataset_dir, const std::string &annotation_file,
                                   const std::string &task = "Detection", const bool &decode = false,
@@ -181,12 +196,12 @@ std::shared_ptr<CSVDataset> CSV(const std::vector<std::string> &dataset_files, c

 /// \brief Function to create an ImageFolderDataset
 /// \notes A source dataset that reads images from a tree of directories
-///    All images within one folder have the same label
-///    The generated dataset has two columns ['image', 'label']
+///     All images within one folder have the same label
+///     The generated dataset has two columns ['image', 'label']
 /// \param[in] dataset_dir Path to the root directory that contains the dataset
 /// \param[in] decode A flag to decode in ImageFolder
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`,
-///    A `RandomSampler` will be used to randomly iterate the entire dataset
+///     A `RandomSampler` will be used to randomly iterate the entire dataset
 /// \param[in] extensions File extensions to be read
 /// \param[in] class_indexing a class name to label map
 /// \return Shared pointer to the current ImageFolderDataset
@@ -200,9 +215,9 @@ std::shared_ptr<ImageFolderDataset> ImageFolder(const std::string &dataset_dir,
 /// \param[in] dataset_file The dataset file to be read
 /// \param[in] usage Need "train", "eval" or "inference" data (default="train")
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`,
-///    A `RandomSampler` will be used to randomly iterate the entire dataset
+///     A `RandomSampler` will be used to randomly iterate the entire dataset
 /// \param[in] class_indexing A str-to-int mapping from label name to index (default={}, the folder
-///    names will be sorted alphabetically and each class will be given a unique index starting from 0).
+///     names will be sorted alphabetically and each class will be given a unique index starting from 0).
 /// \param[in] decode Decode the images after reading (default=false).
 /// \return Shared pointer to the current ManifestDataset
 std::shared_ptr<ManifestDataset> Manifest(std::string dataset_file, std::string usage = "train",
@@ -214,7 +229,7 @@ std::shared_ptr<ManifestDataset> Manifest(std::string dataset_file, std::string
 /// \notes The generated dataset has two columns ['image', 'label']
 /// \param[in] dataset_dir Path to the root directory that contains the dataset
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`,
-///    A `RandomSampler` will be used to randomly iterate the entire dataset
+///     A `RandomSampler` will be used to randomly iterate the entire dataset
 /// \return Shared pointer to the current MnistDataset
 std::shared_ptr<MnistDataset> Mnist(const std::string &dataset_dir,
                                     const std::shared_ptr<SamplerObj> &sampler = nullptr);
@@ -245,17 +260,17 @@ std::shared_ptr<RandomDataset> RandomData(const int32_t &total_rows = 0, T schem
 /// \brief Function to create a TextFileDataset
 /// \notes The generated dataset has one column ['text']
 /// \param[in] dataset_files List of files to be read to search for a pattern of files. The list
-///    will be sorted in a lexicographical order.
+///     will be sorted in a lexicographical order.
 /// \param[in] num_samples The number of samples to be included in the dataset.
-///    (Default = 0 means all samples.)
-/// \param[in] shuffle The mode for shuffling data every epoch. (Default=ShuffleMode::kGlobal)
-///    Can be any of:
-///    ShuffleMode::kFalse - No shuffling is performed.
-///    ShuffleMode::kFiles - Shuffle files only.
-///    ShuffleMode::kGlobal - Shuffle both the files and samples.
+///     (Default = 0 means all samples.)
+/// \param[in] shuffle The mode for shuffling data every epoch. (Default=ShuffleMode.kGlobal)
+///     Can be any of:
+///     ShuffleMode.kFalse - No shuffling is performed.
+///     ShuffleMode.kFiles - Shuffle files only.
+///     ShuffleMode.kGlobal - Shuffle both the files and samples.
 /// \param[in] num_shards Number of shards that the dataset should be divided into. (Default = 1)
 /// \param[in] shard_id The shard ID within num_shards. This argument should be
-///    specified only when num_shards is also specified. (Default = 0)
+///     specified only when num_shards is also specified. (Default = 0)
 /// \return Shared pointer to the current TextFileDataset
 std::shared_ptr<TextFileDataset> TextFile(const std::vector<std::string> &dataset_files, int64_t num_samples = 0,
                                           ShuffleMode shuffle = ShuffleMode::kGlobal, int32_t num_shards = 1,
@@ -263,16 +278,16 @@ std::shared_ptr<TextFileDataset> TextFile(const std::vector<std::string> &datase

 /// \brief Function to create a VOCDataset
 /// \notes The generated dataset has multi-columns :
-///        - task='Detection', column: [['image', dtype=uint8], ['bbox', dtype=float32], ['label', dtype=uint32],
-///                                     ['difficult', dtype=uint32], ['truncate', dtype=uint32]].
-///        - task='Segmentation', column: [['image', dtype=uint8], ['target',dtype=uint8]].
+///     - task='Detection', column: [['image', dtype=uint8], ['bbox', dtype=float32], ['label', dtype=uint32],
+///                                  ['difficult', dtype=uint32], ['truncate', dtype=uint32]].
+///     - task='Segmentation', column: [['image', dtype=uint8], ['target',dtype=uint8]].
 /// \param[in] dataset_dir Path to the root directory that contains the dataset
 /// \param[in] task Set the task type of reading voc data, now only support "Segmentation" or "Detection"
 /// \param[in] mode Set the data list txt file to be readed
 /// \param[in] class_indexing A str-to-int mapping from label name to index
 /// \param[in] decode Decode the images after reading
 /// \param[in] sampler Object used to choose samples from the dataset. If sampler is `nullptr`, A `RandomSampler`
-///    will be used to randomly iterate the entire dataset
+///     will be used to randomly iterate the entire dataset
 /// \return Shared pointer to the current Dataset
 std::shared_ptr<VOCDataset> VOC(const std::string &dataset_dir, const std::string &task = "Segmentation",
                                 const std::string &mode = "train",
@@ -335,9 +350,9 @@ class Dataset : public std::enable_shared_from_this<Dataset> {
   /// \notes Combines batch_size number of consecutive rows into batches
   /// \param[in] batch_size Path to the root directory that contains the dataset
   /// \param[in] drop_remainder Determines whether or not to drop the last possibly incomplete
-  ///    batch. If true, and if there are less than batch_size rows
-  ///    available to make the last batch, then those rows will
-  ///    be dropped and not propagated to the next node
+  ///     batch. If true, and if there are less than batch_size rows
+  ///     available to make the last batch, then those rows will
+  ///     be dropped and not propagated to the next node
   /// \return Shared pointer to the current BatchDataset
   std::shared_ptr<BatchDataset> Batch(int32_t batch_size, bool drop_remainder = false);

@@ -368,16 +383,16 @@ class Dataset : public std::enable_shared_from_this<Dataset> {
   /// \brief Function to create a MapDataset
   /// \notes Applies each operation in operations to this dataset
   /// \param[in] operations Vector of operations to be applied on the dataset. Operations are
-  ///    applied in the order they appear in this list
+  ///     applied in the order they appear in this list
   /// \param[in] input_columns Vector of the names of the columns that will be passed to the first
-  ///    operation as input. The size of this list must match the number of
-  ///    input columns expected by the first operator. The default input_columns
-  ///    is the first column
+  ///     operation as input. The size of this list must match the number of
+  ///     input columns expected by the first operator. The default input_columns
+  ///     is the first column
   /// \param[in] output_columns Vector of names assigned to the columns outputted by the last operation
-  ///    This parameter is mandatory if len(input_columns) != len(output_columns)
-  ///    The size of this list must match the number of output columns of the
-  ///    last operation. The default output_columns will have the same
-  ///    name as the input columns, i.e., the columns will be replaced
+  ///     This parameter is mandatory if len(input_columns) != len(output_columns)
+  ///     The size of this list must match the number of output columns of the
+  ///     last operation. The default output_columns will have the same
+  ///     name as the input columns, i.e., the columns will be replaced
   /// \param[in] project_columns A list of column names to project
   /// \return Shared pointer to the current MapDataset
   std::shared_ptr<MapDataset> Map(std::vector<std::shared_ptr<TensorOperation>> operations,
@@ -404,7 +419,7 @@ class Dataset : public std::enable_shared_from_this<Dataset> {
   /// \param[in] count Number of times the dataset should be repeated
   /// \return Shared pointer to the current Dataset
   /// \note Repeat will return shared pointer to `Dataset` instead of `RepeatDataset`
-  ///    due to a limitation in the current implementation
+  ///     due to a limitation in the current implementation
   std::shared_ptr<Dataset> Repeat(int32_t count = -1);

   /// \brief Function to create a Shuffle Dataset
@@ -506,6 +521,31 @@ class SchemaObj {
 // DERIVED DATASET CLASSES FOR LEAF-NODE DATASETS
 // (In alphabetical order)

+class AlbumDataset : public Dataset {
+ public:
+  /// \brief Constructor
+  AlbumDataset(const std::string &dataset_dir, const std::string &data_schema,
+               const std::vector<std::string> &column_names, bool decode, const std::shared_ptr<SamplerObj> &sampler);
+
+  /// \brief Destructor
+  ~AlbumDataset() = default;
+
+  /// \brief a base class override function to create a runtime dataset op object from this class
+  /// \return shared pointer to the newly created DatasetOp
+  std::vector<std::shared_ptr<DatasetOp>> Build() override;
+
+  /// \brief Parameters validation
+  /// \return bool true if all the params are valid
+  bool ValidateParams() override;
+
+ private:
+  std::string dataset_dir_;
+  std::string schema_path_;
+  std::vector<std::string> column_names_;
+  bool decode_;
+  std::shared_ptr<SamplerObj> sampler_;
+};
+
 class CelebADataset : public Dataset {
  public:
   /// \brief Constructor

tests/ut/cpp/dataset/CMakeLists.txt

@@ -5,6 +5,7 @@ SET(DE_UT_SRCS
         common/cvop_common.cc
         common/bboxop_common.cc
         auto_contrast_op_test.cc
+	album_op_test.cc
         batch_op_test.cc
         bit_functions_test.cc
         storage_container_test.cc
@@ -101,6 +102,7 @@ SET(DE_UT_SRCS
         c_api_samplers_test.cc
         c_api_transforms_test.cc
         c_api_dataset_ops_test.cc
+        c_api_dataset_album_test.cc
         c_api_dataset_cifar_test.cc
         c_api_dataset_clue_test.cc
         c_api_dataset_coco_test.cc

tests/ut/cpp/dataset/album_op_test.cc

@@ -0,0 +1,208 @@
+/**
+ * Copyright 2020 Huawei Technologies Co., Ltd
+ *
+ * Licensed under the Apache License, Version 2.0 (the "License");
+ * you may not use this file except in compliance with the License.
+ * You may obtain a copy of the License at
+ *
+ * http://www.apache.org/licenses/LICENSE-2.0
+ *
+ * Unless required by applicable law or agreed to in writing, software
+ * distributed under the License is distributed on an "AS IS" BASIS,
+ * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+ * See the License for the specific language governing permissions and
+ * limitations under the License.
+ */
+#include <fstream>
+#include <iostream>
+#include <memory>
+#include <string>
+#include "common/common.h"
+#include "minddata/dataset/core/client.h"
+#include "minddata/dataset/core/global_context.h"
+#include "minddata/dataset/engine/datasetops/source/album_op.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/distributed_sampler.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/pk_sampler.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/random_sampler.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/sampler.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/sequential_sampler.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/subset_random_sampler.h"
+#include "minddata/dataset/engine/datasetops/source/sampler/weighted_random_sampler.h"
+#include "minddata/dataset/util/path.h"
+#include "minddata/dataset/util/status.h"
+#include "gtest/gtest.h"
+#include "utils/log_adapter.h"
+#include "securec.h"
+#include "minddata/dataset/include/datasets.h"
+#include "minddata/dataset/include/transforms.h"
+
+using namespace mindspore::dataset;
+using mindspore::MsLogLevel::ERROR;
+using mindspore::ExceptionType::NoExceptionType;
+using mindspore::LogStream;
+
+std::shared_ptr<BatchOp> Batch(int batch_size = 1, bool drop = false, int rows_per_buf = 2);
+
+std::shared_ptr<RepeatOp> Repeat(int repeat_cnt);
+
+std::shared_ptr<ExecutionTree> Build(std::vector<std::shared_ptr<DatasetOp>> ops);
+
+std::shared_ptr<AlbumOp> Album(int64_t num_works, int64_t rows, int64_t conns, std::string path,
+                                           bool shuf = false, std::unique_ptr<Sampler> sampler = nullptr,
+                                           bool decode = false) {
+  std::shared_ptr<AlbumOp> so;
+  AlbumOp::Builder builder;
+  Status rc = builder.SetNumWorkers(num_works)
+                     .SetAlbumDir(path)
+                     .SetRowsPerBuffer(rows)
+                     .SetOpConnectorSize(conns)
+                     .SetExtensions({".json"})
+                     .SetSampler(std::move(sampler))
+                     .SetDecode(decode)
+                     .Build(&so);
+  return so;
+}
+
+std::shared_ptr<AlbumOp> AlbumSchema(int64_t num_works, int64_t rows, int64_t conns, std::string path,
+                                       std::string schema_file, std::vector<std::string> column_names = {},
+                                       bool shuf = false, std::unique_ptr<Sampler> sampler = nullptr,
+                                       bool decode = false) {
+  std::shared_ptr<AlbumOp> so;
+  AlbumOp::Builder builder;
+  Status rc = builder.SetNumWorkers(num_works)
+    .SetSchemaFile(schema_file)
+    .SetColumnsToLoad(column_names)
+    .SetAlbumDir(path)
+    .SetRowsPerBuffer(rows)
+    .SetOpConnectorSize(conns)
+    .SetExtensions({".json"})
+    .SetSampler(std::move(sampler))
+    .SetDecode(decode)
+    .Build(&so);
+  return so;
+}
+
+class MindDataTestAlbum : public UT::DatasetOpTesting {
+ protected:
+};
+
+TEST_F(MindDataTestAlbum, TestSequentialAlbumWithSchema) {
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  std::string schema_file = datasets_root_path_ + "/testAlbum/datasetSchema.json";
+  std::vector<std::string> column_names = {"image", "label", "id"};
+  auto tree = Build({AlbumSchema(16, 2, 32, folder_path, schema_file, column_names, false), Repeat(2)});
+  tree->Prepare();
+  Status rc = tree->Launch();
+  if (rc.IsError()) {
+    MS_LOG(ERROR) << "Return code error detected during tree launch: " <<  ".";
+    EXPECT_TRUE(false);
+  } else {
+    DatasetIterator di(tree);
+    TensorMap tensor_map;
+    di.GetNextAsMap(&tensor_map);
+    EXPECT_TRUE(rc.IsOk());
+    uint64_t i = 0;
+    int32_t label = 0;
+    while (tensor_map.size() != 0) {
+      tensor_map["label"]->GetItemAt<int32_t>(&label, {});
+      MS_LOG(DEBUG) << "row: " << i << "\t" << tensor_map["image"]->shape() << "label:" << label << "label shape"
+                    << tensor_map["label"] << "\n";
+      i++;
+      di.GetNextAsMap(&tensor_map);
+    }
+    MS_LOG(INFO) << "got rows" << i << "\n";
+    EXPECT_TRUE(i == 14);
+  }
+}
+
+TEST_F(MindDataTestAlbum, TestSequentialAlbumWithSchemaNoOrder) {
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  std::string schema_file = datasets_root_path_ + "/testAlbum/datasetSchema.json";
+  auto tree = Build({AlbumSchema(16, 2, 32, folder_path, schema_file), Repeat(2)});
+  tree->Prepare();
+  Status rc = tree->Launch();
+  if (rc.IsError()) {
+    MS_LOG(ERROR) << "Return code error detected during tree launch: " << ".";
+    EXPECT_TRUE(false);
+  } else {
+    DatasetIterator di(tree);
+    TensorMap tensor_map;
+    di.GetNextAsMap(&tensor_map);
+    EXPECT_TRUE(rc.IsOk());
+    uint64_t i = 0;
+    int32_t label = 0;
+    while (tensor_map.size() != 0) {
+      tensor_map["label"]->GetItemAt<int32_t>(&label, {});
+      MS_LOG(DEBUG) << "row: " << i << "\t" << tensor_map["image"]->shape() << "label:" << label << "label shape"
+                    << tensor_map["label"] << "\n";
+      i++;
+      di.GetNextAsMap(&tensor_map);
+    }
+    MS_LOG(INFO) << "got rows" << i << "\n";
+    EXPECT_TRUE(i == 14);
+  }
+}
+
+TEST_F(MindDataTestAlbum, TestSequentialAlbumWithSchemaFloat) {
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  // add the priority column
+  std::string schema_file = datasets_root_path_ + "/testAlbum/floatSchema.json";
+  auto tree = Build({AlbumSchema(16, 2, 32, folder_path, schema_file), Repeat(2)});
+  tree->Prepare();
+  Status rc = tree->Launch();
+  if (rc.IsError()) {
+    MS_LOG(ERROR) << "Return code error detected during tree launch: " << ".";
+    EXPECT_TRUE(false);
+  } else {
+    DatasetIterator di(tree);
+    TensorMap tensor_map;
+    di.GetNextAsMap(&tensor_map);
+    EXPECT_TRUE(rc.IsOk());
+    uint64_t i = 0;
+    int32_t label = 0;
+    double priority = 0;
+    while (tensor_map.size() != 0) {
+      tensor_map["label"]->GetItemAt<int32_t>(&label, {});
+      tensor_map["_priority"]->GetItemAt<double>(&priority, {});
+      MS_LOG(DEBUG) << "row: " << i << "\t" << tensor_map["image"]->shape() << "label:" << label << "label shape"
+                    << tensor_map["label"]  << "priority: " << priority << "\n";
+      i++;
+      di.GetNextAsMap(&tensor_map);
+    }
+    MS_LOG(INFO) << "got rows" << i << "\n";
+    EXPECT_TRUE(i == 14);
+  }
+}
+
+TEST_F(MindDataTestAlbum, TestSequentialAlbumWithFullSchema) {
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  // add the priority column
+  std::string schema_file = datasets_root_path_ + "/testAlbum/fullSchema.json";
+  auto tree = Build({AlbumSchema(16, 2, 32, folder_path, schema_file), Repeat(2)});
+  tree->Prepare();
+  Status rc = tree->Launch();
+  if (rc.IsError()) {
+    MS_LOG(ERROR) << "Return code error detected during tree launch: " << ".";
+    EXPECT_TRUE(false);
+  } else {
+    DatasetIterator di(tree);
+    TensorMap tensor_map;
+    di.GetNextAsMap(&tensor_map);
+    EXPECT_TRUE(rc.IsOk());
+    uint64_t i = 0;
+    int32_t label = 0;
+    double priority = 0;
+    while (tensor_map.size() != 0) {
+      tensor_map["label"]->GetItemAt<int32_t>(&label, {});
+      tensor_map["_priority"]->GetItemAt<double>(&priority, {});
+      MS_LOG(DEBUG) << "row: " << i << "\t" << tensor_map["image"]->shape() << "label:" << label << "label shape"
+                    << tensor_map["label"]  << "priority: " << priority << " embedding : " <<
+		    tensor_map["_embedding"]->shape() << "\n";
+      i++;
+      di.GetNextAsMap(&tensor_map);
+    }
+    MS_LOG(INFO) << "got rows" << i << "\n";
+    EXPECT_TRUE(i == 14);
+  }
+}
+

tests/ut/cpp/dataset/c_api_dataset_album_test.cc

@@ -0,0 +1,136 @@
+/**
+ * Copyright 2020 Huawei Technologies Co., Ltd
+ *
+ * Licensed under the Apache License, Version 2.0 (the "License");
+ * you may not use this file except in compliance with the License.
+ * You may obtain a copy of the License at
+ *
+ * http://www.apache.org/licenses/LICENSE-2.0
+ *
+ * Unless required by applicable law or agreed to in writing, software
+ * distributed under the License is distributed on an "AS IS" BASIS,
+ * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+ * See the License for the specific language governing permissions and
+ * limitations under the License.
+ */
+#include "common/common.h"
+#include "minddata/dataset/include/datasets.h"
+
+using namespace mindspore::dataset::api;
+using mindspore::dataset::Tensor;
+
+class MindDataTestPipeline : public UT::DatasetOpTesting {
+ protected:
+};
+
+TEST_F(MindDataTestPipeline, TestAlbumBasic) {
+  MS_LOG(INFO) << "Doing MindDataTestPipeline-TestAlbumBasic.";
+
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  std::string schema_file = datasets_root_path_ + "/testAlbum/datasetSchema.json";
+  std::vector<std::string> column_names = {"image", "label", "id"};
+  // Create a Album Dataset
+  std::shared_ptr<Dataset> ds = Album(folder_path, schema_file, column_names);
+  EXPECT_NE(ds, nullptr);
+
+  // Create an iterator over the result of the above dataset
+  // This will trigger the creation of the Execution Tree and launch it.
+  std::shared_ptr<Iterator> iter = ds->CreateIterator();
+  EXPECT_NE(iter, nullptr);
+
+  // Iterate the dataset and get each row
+  std::unordered_map<std::string, std::shared_ptr<Tensor>> row;
+  iter->GetNextRow(&row);
+
+  uint64_t i = 0;
+  while (row.size() != 0) {
+    i++;
+    auto image = row["image"];
+    MS_LOG(INFO) << "Tensor image shape: " << image->shape();
+    iter->GetNextRow(&row);
+  }
+
+  EXPECT_EQ(i, 7);
+
+  // Manually terminate the pipeline
+  iter->Stop();
+}
+
+TEST_F(MindDataTestPipeline, TestAlbumDecode) {
+  MS_LOG(INFO) << "Doing MindDataTestPipeline-TestAlbumDecode.";
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  std::string schema_file = datasets_root_path_ + "/testAlbum/datasetSchema.json";
+  std::vector<std::string> column_names = {"image", "label", "id"};
+  // Create a Album Dataset
+  std::shared_ptr<Dataset> ds = Album(folder_path, schema_file, column_names, true);
+  EXPECT_NE(ds, nullptr);
+
+  // Create an iterator over the result of the above dataset
+  // This will trigger the creation of the Execution Tree and launch it.
+  std::shared_ptr<Iterator> iter = ds->CreateIterator();
+  EXPECT_NE(iter, nullptr);
+
+  // Iterate the dataset and get each row
+  std::unordered_map<std::string, std::shared_ptr<Tensor>> row;
+  iter->GetNextRow(&row);
+
+  uint64_t i = 0;
+  while (row.size() != 0) {
+    i++;
+    auto image = row["image"];
+    auto shape = image->shape();
+    MS_LOG(INFO) << "Tensor image shape size: " << shape.Size();
+    MS_LOG(INFO) << "Tensor image shape: " << image->shape();
+    EXPECT_GT(shape.Size(), 1); // Verify decode=true took effect
+    iter->GetNextRow(&row);
+  }
+
+  EXPECT_EQ(i, 7);
+
+  // Manually terminate the pipeline
+  iter->Stop();
+}
+
+TEST_F(MindDataTestPipeline, TestAlbumNumSamplers) {
+  MS_LOG(INFO) << "Doing MindDataTestPipeline-TestAlbumNumSamplers.";
+
+  std::string folder_path = datasets_root_path_ + "/testAlbum/images";
+  std::string schema_file = datasets_root_path_ + "/testAlbum/datasetSchema.json";
+  std::vector<std::string> column_names = {"image", "label", "id"};
+  // Create a Album Dataset
+  std::shared_ptr<Dataset> ds = Album(folder_path, schema_file, column_names, true, SequentialSampler(0, 1));
+  EXPECT_NE(ds, nullptr);
+
+  // Create an iterator over the result of the above dataset
+  // This will trigger the creation of the Execution Tree and launch it.
+  std::shared_ptr<Iterator> iter = ds->CreateIterator();
+  EXPECT_NE(iter, nullptr);
+
+  // Iterate the dataset and get each row
+  std::unordered_map<std::string, std::shared_ptr<Tensor>> row;
+  iter->GetNextRow(&row);
+
+  uint64_t i = 0;
+  while (row.size() != 0) {
+    i++;
+    auto image = row["image"];
+    MS_LOG(INFO) << "Tensor image shape: " << image->shape();
+    iter->GetNextRow(&row);
+  }
+
+  EXPECT_EQ(i, 1);
+
+  // Manually terminate the pipeline
+  iter->Stop();
+}
+
+TEST_F(MindDataTestPipeline, TestAlbumError) {
+  MS_LOG(INFO) << "Doing MindDataTestPipeline-TestAlbumError.";
+  std::string folder_path = datasets_root_path_ + "/testAlbum/ima";
+  std::string schema_file = datasets_root_path_ + "/testAlbum/datasetSchema.json";
+  std::vector<std::string> column_names = {"image", "label", "id"};
+  // Create a Album Dataset
+  std::shared_ptr<Dataset> ds = Album(folder_path, schema_file, column_names, true, SequentialSampler(0, 1));
+
+  EXPECT_EQ(ds, nullptr);
+}

tests/ut/cpp/runtest.sh

@@ -32,6 +32,8 @@ export GLOG_v=2

 ## prepare data for dataset & mindrecord
 cp -fr $PROJECT_PATH/tests/ut/data ${PROJECT_PATH}/build/mindspore/tests/ut/cpp/
+## prepare album dataset, uses absolute path so has to be generated
+python ${PROJECT_PATH}/build/mindspore/tests/ut/cpp/data/dataset/testAlbum/gen_json.py

 if [ $# -gt 0 ]; then
   ./ut_tests --gtest_filter=$1

tests/ut/data/dataset/testAlbum/bin/sample.bin

@@ -0,0 +1 @@
+just some random stuff

tests/ut/data/dataset/testAlbum/datasetSchema.json

@@ -0,0 +1,16 @@
+{
+  "columns": {
+    "image": {
+      "type": "uint8",
+      "rank": 1
+    },
+    "label" : {
+      "type": "string",
+      "rank": 1
+    },
+    "id" : {
+      "type": "int64",
+      "rank": 0
+    }
+  }
+}

tests/ut/data/dataset/testAlbum/floatSchema.json

@@ -5,7 +5,7 @@
       "rank": 1
     },
     "label" : {
-      "type": "int32",
+      "type": "string",
       "rank": 1
     },
     "id" : {

tests/ut/data/dataset/testAlbum/fullSchema.json

@@ -5,7 +5,7 @@
       "rank": 1
     },
     "label" : {
-      "type": "int32",
+      "type": "string",
       "rank": 1
     },
     "id" : {

tests/ut/data/dataset/testAlbum/gen_json.py

@@ -2,21 +2,21 @@ import json
 import os

 def dump_json_from_dict(structure, file_name):
-    with open(file_name + '.json', 'w') as file_path:
-        json.dump(structure, file_path)
+    with open(file_name + '.json', 'w') as fp:
+        json.dump(structure, fp)

 if __name__ == '__main__':
-    # iterate over directory
-    DIRECTORY = "imagefolder"
-    i = 0
+    # iterate over DIRECTORY
+    DIRECTORY = os.path.dirname(os.path.realpath(__file__)) + "/original"
+    PARENT_DIR = os.path.dirname(DIRECTORY)
+    i = -1
     for filename in os.listdir(DIRECTORY):
         default_dict = {}
         default_dict.update(dataset='')
-        default_dict.update(image=(os.path.join(DIRECTORY, filename)))
-        default_dict.update(label=[1, 2])
+        default_dict.update(image=os.path.abspath(os.path.join(DIRECTORY, filename)))
+        default_dict.update(label=['3', '2'])
         default_dict.update(_priority=0.8)
-        default_dict.update(_embedding='sample.bin')
-        default_dict.update(_segmented_image=(os.path.join(DIRECTORY, filename)))
-        default_dict.update(_processed_image=(os.path.join(DIRECTORY, filename)))
+        default_dict.update(_embedding=os.path.abspath(os.path.join(PARENT_DIR, 'sample.bin')))
+        default_dict.update(_processed_image=os.path.abspath(os.path.join(DIRECTORY, filename)))
         i = i + 1
-        dump_json_from_dict(default_dict, 'images/'+str(i))
+        dump_json_from_dict(default_dict, PARENT_DIR + '/images/'+str(i))

tests/ut/data/dataset/testAlbum/images/0.json

@@ -0,0 +1 @@
+{"dataset": "", "image": "original/apple_expect_decoded.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "sample.bin", "_processed_image": "original/apple_expect_decoded.jpg"}

tests/ut/data/dataset/testAlbum/images/1.json

@@ -1 +1 @@
-{"dataset": "", "image": "imagefolder/apple_expect_decoded.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_decoded.jpg", "_processed_image": "imagefolder/apple_expect_decoded.jpg"}
+{"dataset": "", "image": "testAlbum//testAlbum/original/apple_expect_resize_bilinear.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "testAlbum//testAlbum/sample.bin", "_processed_image": "testAlbum//testAlbum/original/apple_expect_resize_bilinear.jpg"}

tests/ut/data/dataset/testAlbum/images/2.json

@@ -1 +1 @@
-{"dataset": "", "image": "imagefolder/apple_expect_resize_bilinear.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_resize_bilinear.jpg", "_processed_image": "imagefolder/apple_expect_resize_bilinear.jpg"}
+{"dataset": "", "image": "testAlbum//testAlbum/original/apple_expect_changemode.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "testAlbum//testAlbum/sample.bin", "_processed_image": "testAlbum//testAlbum/original/apple_expect_changemode.jpg"}

tests/ut/data/dataset/testAlbum/images/3.json

@@ -1 +1 @@
-{"dataset": "", "image": "imagefolder/apple_expect_changemode.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_changemode.jpg", "_processed_image": "imagefolder/apple_expect_changemode.jpg"}
+{"dataset": "", "image": "testAlbum//testAlbum/original/apple_expect_not_flip.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "testAlbum//testAlbum/sample.bin", "_processed_image": "testAlbum//testAlbum/original/apple_expect_not_flip.jpg"}

tests/ut/data/dataset/testAlbum/images/4.json

@@ -1 +1 @@
-{"dataset": "", "image": "imagefolder/apple_expect_not_flip.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_not_flip.jpg", "_processed_image": "imagefolder/apple_expect_not_flip.jpg"}
+{"dataset": "", "image": "testAlbum//testAlbum/original/apple_expect_flipped_horizontal.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "testAlbum//testAlbum/sample.bin", "_processed_image": "testAlbum//testAlbum/original/apple_expect_flipped_horizontal.jpg"}

tests/ut/data/dataset/testAlbum/images/5.json

@@ -1 +1 @@
-{"dataset": "", "image": "imagefolder/apple_expect_flipped_horizontal.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_flipped_horizontal.jpg", "_processed_image": "imagefolder/apple_expect_flipped_horizontal.jpg"}
+{"dataset": "", "image": "testAlbum//testAlbum/original/apple_expect_rescaled.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "testAlbum//testAlbum/sample.bin", "_processed_image": "testAlbum//testAlbum/original/apple_expect_rescaled.jpg"}

tests/ut/data/dataset/testAlbum/images/6.json

@@ -1 +1 @@
-{"dataset": "", "image": "imagefolder/apple_expect_rescaled.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_rescaled.jpg", "_processed_image": "imagefolder/apple_expect_rescaled.jpg"}
+{"dataset": "", "image": "testAlbum//testAlbum/original/apple_expect_flipped_vertical.jpg", "label": ["3", "2"], "_priority": 0.8, "_embedding": "testAlbum//testAlbum/sample.bin", "_processed_image": "testAlbum//testAlbum/original/apple_expect_flipped_vertical.jpg"}

tests/ut/data/dataset/testAlbum/images/7.json

@@ -1 +0,0 @@
-{"dataset": "", "image": "imagefolder/apple_expect_flipped_vertical.jpg", "label": [1, 2], "_priority": 0.8, "_embedding": "sample.bin", "_segmented_image": "imagefolder/apple_expect_flipped_vertical.jpg", "_processed_image": "imagefolder/apple_expect_flipped_vertical.jpg"}
